Surface-mount electrical enclosure 900004

commercialoutdoorequipped

Product overview
Complete watertight control cabinets, manufactured and fitted according to the number of cables/mats and required power. Cabinets are available for 230 V and 400 V systems and are assembled to project-specific requirements.

Connection box
Control cabinets are custom-assembled per project. The standard version (according to NEN1010) includes waterproof cable entries, magnetic circuits (relays), circuit breakers, earth-leakage switches (RCDs), terminal strips for simplified connection of power and heating cables, and dedicated outdoor sensor units. Installation must follow the wiring diagram provided in the switch box.

Available models
Art.nr. | Description | kW | Cabinet dimensions | Unit | Notes
900004 | MAGNUM Outdoor control cabinet | 3.6 kW | 430 x 310 x 160 mm | units/1 | incl. ETO2-4550 DIN-rail thermostat and 2x ETOG-56 sensor units
900010 | MAGNUM Outdoor control cabinet | 10 kW | 500 x 400 x 200 mm | units/1 | incl. ETO2-4550 DIN-rail thermostat and 2x ETOG-56 sensor units
900020 | MAGNUM Outdoor control cabinet | 20 kW | 500 x 400 x 200 mm | units/1 | incl. ETO2-4550 DIN-rail thermostat and 2x ETOG-56 sensor units
900030 | MAGNUM Outdoor control cabinet | 30 kW | 700 x 520 x 253 mm | units/1 | incl. ETO2-4550 DIN-rail thermostat and 2x ETOG-56 sensor units
900040 | MAGNUM Outdoor control cabinet | 40 kW | 700 x 520 x 253 mm | units/1 | incl. ETO2-4550 DIN-rail thermostat and 2x ETOG-56 sensor units
900050 | MAGNUM Outdoor control cabinet | 50 kW | 700 x 520 x 253 mm | units/1 | incl. ETO2-4550 DIN-rail thermostat and 2x ETOG-56 sensor units

Specifications
ETO2-4550 DIN-rail | Thermostat 0°C / +5°C 230V
2x ETOG-56 Sensor units | Humidity & temperature
Potential-free contacts | 3 x 16 A
Required solenoid circuits (relays) | 230 V / 400 V
Required installation circuit breakers | 16 A
Connection terminals | For mounting power cables
Indicator lights | As specified per unit
Warranty | 2 year

Technical features

• Watertight control cabinets, custom-assembled per project
• Suitable for 230 V and 400 V systems
• Standard equipment: waterproof cable entries, magnetic circuits (relays), circuit breakers, earth-leakage switches, terminal strips
• Includes ETO2-4550 DIN-rail thermostat and 2x ETOG-56 sensor units (on listed units)
• Potential-free contacts: 3 x 16 A
• Required installation circuit breakers: 16 A
• Available cabinet dimensions: 430 x 310 x 160 mm; 500 x 400 x 200 mm; 700 x 520 x 253 mm
• Power options: 3.6 kW; 10 kW; 20 kW; 30 kW; 40 kW; 50 kW
• Warranty: 2 year
