Handicapped drinking fountain PLF12FPMCDY

vandal-proofcoldcompletely recessed

The PLF12FPMCDY is a manually activated, fully recessed drinking fountain featuring a matching cup filler, cup dispenser, and disposer. It delivers 90 liters per hour of 10°C water at 21°C ambient temperature. These surface-mounted fountains are activated via a vandal-resistant touch button and include an integrated cup dispenser, saving space. The cabinet is finished in brushed stainless steel and uses R-134a refrigerant. Suitable for public buildings, gyms, sports complexes, hospitals, schools, and offices. - Activation: Mechanical (Constant Flow Bubbler) - Dimensions: 1410(H) x 610(W) x 13(D) mm (274 recessed) - Max. Power Consumption: 620W - Performance: 90 LPH Rated Capacity & Base Rate (10°C in 21°C ambient temp.) - Power Supply: 220-240V, 50/60 Hz - Water Type: Cold - Micron Rating: Built-in 100 micron strainer Additional features include ADA compliance, lead-free waterways, stainless steel panels, and a high-efficiency cooling system. Options: - Carafe fillers (factory installed): 030239-003 - Installation Kit Product Assurance And Certifications: Complies with ANSI A117.1 and ADA. Meets all relevant CE directives (LVD, EMC, RoHS) and ANSI/NSF 61.
