Plexiglas® bus shelter Turin

zinc-plated steelwoodpainted steel

Overview
The Turin bus shelter in raw softwood offers a natural appearance combined with functionality for urban environments. Designed to integrate with streetscapes, it provides covered waiting space for public transport users and can be adapted to site requirements.

Configuration options

• Available lengths: 2000 mm or 3000 mm
• Structure variants: two side claddings; two side claddings with windows
• Optional half front panel for 2000 mm (ref 310012) and 3000 mm (ref 310015)

Technical features

• Reference: 310011
• Available lengths (mm): 2000; 3000
• Total depth (mm): 1200
• Height under roof (mm): 2100
• Side and rear cladding: 21 mm flat cladding on frame, softwood autoclave-treated class 4, delivered pre-assembled
• Roof material: lacquered steel
• Window material: 6 mm plexiglass
• Finish: raw softwood cladding
• Fixing: base plates with 90×90×65 zinc-plated steel sealing brackets and A2 stainless steel screws supplied
• Options: half front panel for 2000 mm (ref 310012) and 3000 mm (ref 310015)
• Availability: 5 weeks
• Weight: 274 kg

Technical files
Technical documentation and specification sheet are available in the distributor area (download subject to access rights).
