Recessed downlight MAGIQ

LEDlinearIP20

Description
MAGIQ recessed downlights are precision luminaires for architectural and interior lighting. Designed for architects and planners favoring linear forms, MAGIQ combines a minimalist appearance with advanced reflector technology to provide high light output and excellent glare control suitable for accent and general lighting applications.

Product overview

• Available as a 5-light or 10-light downlight variant
• State-of-the-art reflector technology for high light output and excellent glare control (up to UGR < 10)
• Installation frames available in all PROLICHT powder-coated colours; covers available in black and white
• Three selectable beam angles (from medium to wide flood) for precise adaptation to architectural requirements

Product highlights

• Lumen: 1295 lm
• LED Module: 14.3 W
• Dimmer: Depending on driver
• Dimensions: L: 178 mm, W: 45 mm, D: 80 mm (Cut-Out 40 x 174 mm)
• Colour Temperature: 2700 K
• Beam angle: Spot 20°

Technical specifications

• Article / internal code shown on page: 220-1540 03 03 27 22
• Luminous flux: 1295 lm
• LED module power: 14.3 W
• System efficacy example: 90.6 lm/W (as indicated on page)
• Dimmer behavior: depends on chosen driver
• Dimensions: Length 178 mm, Width 45 mm, Depth 80 mm
• Cut-out required: 40 x 174 mm
• Colour temperature: 2700 K
• Beam angle (spot): 20°
• Mounting type: recessed installation
