Sidewalk mountable curb BORDURE T2

streetconcreteoutdoor

DESCRIPTION
Bordure T2 75×15
OLD STONE APPEARANCE
Unit of sale (U) = Lm
equivalence: 1 lm = 1.5 kerbs

Bordure T2 75×15×25 — OLD STONE APPEARANCE
Geometric dimensions (cm):
length: 75
width: 15
thickness (cm): 25
weight (kg/U): 90
Packaging (U/pal): 13.5 (disposable pallet 110×90)

Low kerb T2 75×15
OLD STONE APPEARANCE
Unit of sale (U) = Lm
equivalence: 1 lm = 1.5 kerbs
Geometric dimensions (cm):
length: 75
width: 15
thickness (cm): 15
weight (kg/U): 54
Packaging (U/pal): 22.5 (disposable pallet 110×90)

TECHNICAL SPECIFICATIONS
Mechanical characteristics:
splitting tensile strength (MPa): 5.2
water absorption: < 6%
freeze/thaw resistance: 0.758 kg/m²
slip resistance: average 62

Regulatory framework:
NF – EN – 1339
Fascicle 29 dated 30 May 2021
NF – 98 335

INSTALLATION

• The indications provided by standard NF P 98 335 and fascicle 29 of the CCTG prevail.
• Installation is carried out between +5°C and +30°C on a sound substrate.
• Mortars are prepared or supplied progressively as work advances.
• The mortar bedding is leveled with a screed and executed progressively. Its thickness should be as uniform as possible (~4 cm).
• Units must be dampened, especially in hot conditions.
• During installation, mix products of different colors/shades from different batches.
• Joints are left between units. Joints are filled with mortar at the earliest 24 h after laying and at the latest 72 h after laying.
• Joint width must be reduced as far as product geometry allows but not less than 5 mm.
• Immediately after jointing, the pavement must be cleaned to avoid any film or deposit on the surface.
• Expansion joints must be provided in accordance with normative requirements (10 lm or 20 m²).

MAINTENANCE

• All products in the Replik range are designed to retain a sober and stable surface appearance over time.
• Original colors are more stable compared with more open concrete surfaces.
• Minimal maintenance is generally sufficient; natural patina will develop over time.
• Application of a mineralizing agent will facilitate cleaning and extend the life of the original surface appearance.
• High-pressure cleaners or acidic products are not recommended as they may cause irreversible alterations.
• De-icing salts should be used in reasonable amounts without excess stagnant residues.

COLOUR RANGE
Colour range available for the old stone appearance (visual swatches shown on the page).

ASPECTS
ASPECTS
Old stone appearance

Characteristics / technical specifications

• Model: Bordure T2
• Appearance: old stone
• Unit of sale: Lm (linear metre)
• Equivalence: 1 lm = 1.5 kerbs
• Bordure T2 75×15×25 — length 75 cm, width 15 cm, thickness 25 cm, weight 90 kg/U
• Packaging T2 75×15×25: 13.5 U/pallet (disposable pallet 110×90)
• Low kerb T2 75×15×15 — length 75 cm, width 15 cm, thickness 15 cm, weight 54 kg/U
• Packaging low T2 75×15×15: 22.5 U/pallet (disposable pallet 110×90)
• Splitting tensile strength: 5.2 MPa
• Water absorption: < 6%
• Freeze/thaw resistance: 0.758 kg/m²
• Slip resistance: average 62
• Standards: NF – EN – 1339; Fascicle 29 dated 30 May 2021; NF – 98 335
