Duct air conditioner AJ052BNMDEG/EU

split systemindustrialcommercial

Product overview
The Samsung MA duct indoor unit AJ052BNMDEG/EU is a compact ducted air handling solution for HVAC installations where concealed installation and flexible air distribution are required. The unit offers selectable fan operating ranges and multiple service access points to ease integration and maintenance in commercial and light-industrial applications.

Features

• Ultra-compact design: suitable for installation in limited ceiling voids; certain larger models (20/25 kW) can be split into two parts for simplified installation and servicing.
• Comfort control: indoor discharge temperature management for both cooling and heating via remote control; compatible with ducted systems or AHU-connected setups.
• 3-way service access: slide-fit cover allows maintenance from top, side or bottom to accommodate varied installation constraints.
• Automatic External Static Pressure (ESP): enables selection of an optimal fan operating range to balance sound level and capacity; straightforward to configure on site.

Smart control
Remote temperature control is available via the SmartThings App (requires Wi‑Fi kit). Supported functions include remote on/off, mode selection, scheduling and energy monitoring. Voice control via Bixby 2.0 and Google Assistant is supported where available.

SolarCell Remote Controller (optional)
Optional SolarCell remote provides integrated solar charging (no disposable batteries), USB-C fast charging, slim form factor and a large OLED display for improved usability. Under typical use a full charge can last up to two years.

Technical specifications

• Brand: Samsung
• Type: MA duct
• Commercial model: AJ052BNMDEG/EU
• Indoor unit model name: AJ052BNMDEG/EU
• Available capacity (cooling): 5.2 kW
• Heating capacity: 5.6 kW
• Available power (indoor unit): 1 Phase
• Power supply (indoor unit): 1, 2, 220-240 V, 50 Hz
• Mode/System: HP
• Power input (Cooling / Heating): 50 W / 50 W
• Current input (Cooling / Heating): 0.45 A / 0.45 A
• Fan type: Sirocco Fan / BLDC
• Fan motor (output): 84 x 1 W
• Air flow rate (High / Mid / Low): 14.0 / 9.8 / 5.4 CMM (233 / 163 / 90 l/s)
• External static pressure (Min / Std / Max): 0 / 2 / 5.1 mmAq (0 / 19.6 / 50.0 Pa)
• Liquid pipe (Ø): 6.35 mm (1/4 inch)
• Gas pipe (Ø): 12.7 mm (1/2 inch)
• Drain pipe (Ø): VP25 (OD 32, ID 25) mm
• Field wiring - power source wire: 1.5 ~ 2.5 mm²
• Field wiring - transmission cable: 0.75 ~ 1.5 mm²
• Refrigerant type: R32 (contains fluorinated greenhouse gases, GWP = 675)
• Control method: EEV NOT INCLUDED
• Sound pressure (High / Mid / Low): 33 / 29 / 23 dBA
• Sound power level: 53 dBA
• Net weight (indoor unit): 18.9 kg
• Net dimensions (W x H x D) (indoor unit): 900 x 199 x 440 mm
• Wi‑Fi Kit: N/A
• SmartThings App support: N/A
