Perfect for golf courses, parks and recreation, trails, wetlands, marine, campus facilities and public works applications
Choice of handrail designs and various decking materials
Meets state and federal codes with custom designed load requirements
Non-corrosive and non-combustible materials for safe access
Maintenance free & durable aluminum fabrication for exceptional value over a long life cycle
Environmentally friendly works well in both fresh and salt-water environments
Lightweight material reduces need for heavy equipment during installation
Various enclosure and cover options available
Custom designed to fit your application
5 Year warranty
Our aluminum pedestrian bridges serve as low maintenance crossways for traffic ranging from horses and pedestrians to golf carts. The pedestrian bridges are environmentally friendly and meet state and federal codes.
BUTTERFLY BRIDGES
The Butterfly bridges have an asymmetrical butterfly shaped support. This support takes the even load and torsion forces with maximum effect. The Butterfly bridge is elegant and expressive with a minimum use of material. The length of the Butterfly bridges is from 12 to maximum 24 metres. The steel construction is galvanized. The standard widths of the bridge deck are 2 or 3 metres and often decked in slip resistant Artdeck. The grids are left open at the sides for transparency.
DX-704-J (Jinhae Bridge)
Our custom pedestrian bridges are designed specifically to bring people together. Whether it's connecting communities across rivers or allowing people to safely cross freeways, we specialize in bridging the gap, no matter what the obstacle. The walking surface is made of treated all-natural hardwood. Our ropes are made of steel-loaded polyamide cables with UV guard. Dynamo uses the highest steel content in the industry to ensure long life of the bridges and maximum safety for the pedestrians.
The Cascade is a half-through Pratt truss design. Gator Bridge's Cascade bridge can easily reach medium to large unsupported spans in nearly all pedestrian bridge applications. Choose from many different railing and decking options to make the Cascade bridge uniquely specific to your needs.
The Atlantis is a half-through, Warren truss bridge design. Gator Bridge's Atlantis pre-engineered bridges offer dependable performance in medium-length pedestrian bridge applications. Choose from many different railing and decking options to make the Atlantis bridge the perfect pedestrian bridge for you.
The Gator Bridge Skyway pedestrian bridge is a combination between a Pratt truss and Bow String truss design. Suitable for every pedestrian application, the Skyway pedestrian bridge is designed to support large volumes of traffic. The Skyway bridge was pre-engineered with railway and highway overpasses in mind. However, all Gator Bridge pedestrian bridges can be designed to meet any of your architectural requirements.
The Colonial is a "hidden strength underfoot" design using Gator Bridge's fully-welded box beam construction method. This pedestrian bridge allows for virtually any railing type or aesthetic to be mounted against it. The Colonial pedestrian bridge is pre-engineered for shorter clear spans. The Colonial pedestrian bridge can link to other Colonial bridge sections to achieve longer overall spans, where multiple supports are available.
The Contour bridge design is a Bow String truss with a structurally-arched top chord. Gator Bridge's Contour pedestrian bridge is capable of far-reaching unsupported spans. Additionally, the arching curve of this pre-egineered bridge design will add a beautiful aesthetic and commanding presence to your project landscape.
Thanks to the rigidity of the Trislot grilles they are also used as walkways, bridges, ... for pedestrian traffic. A stainless steel surface, which is not slippery, hard to wear, which drains the rain and remove the dirt from the shoes and looks nice (and if slot is kept small is also heal proof) is the ideal flooring for different outdoor applications.
Trislot can make strength calculation if the grille has to carry a certain load over a certain span.
Gator Bridges are built with integrity and durability in mind, leaving clients with the assurance that the bridge they envision will be the bridge they receive. Our staff of expert engineers and experienced aluminum bridge fabricators are able to assist and advise you through the challenge of creating your custom bridge.
