Luminaires for special uses
More than just lighting.
Do you have unusual requirements in terms of your lighting? Simply give us a call because Lindner can develop customised solutions for you for airports, office complexes, hotels, shopping centres, swimming pools, gymnastics halls and even outside.
For example we have developed an especially flat luminaire casing for integration into closed fire-protective ceiling installations without the need for additional fire-protective boxes. With an overall height of only 38 mm these luminaires are particularly suited to applications with a large number of services above the ceiling void.
Our luminaires for longitudinal soundproofed ceiling installations are also very adaptable. In addition to providing effective lighting, they are also capable of making a significant contribution to the overall acoustic performance of the ceiling.
We can plan, develop, produce and fit your own personal alternatives to daylight.
|
|
Ceiling luminaire with micro prism cover
The luminaire delivers following advantages over the competition:
integrated flush luminaire without mounting frame
installation in narrow ceiling elements
lamp replacement without tools
delivery factory provided, fully integrated in metal ceiling element, including two profiles and lamp
no colour deviation to the ceiling
This ceiling luminaire combines best quality of light with a precise blinding and a uniform light distribution.
|
|
Aqua & Alto - Recessed spots for led
The line of recessed spots for led Aqua & Alto can create scenographic effects
on ceilings, walls and floors. The models Aqua are available with different IP ratings and the presence of a sanded or transparent glass. Alto includes models with fix or adjustable spot, with or without lens.
|
|
FLY- Recessed lighting fittings for indoor use
Collection of round recessed lighting fittings for indoor use ideal to
enlighten all big areas.
The closing frame is made of powder coated die cast aluminium and the
aluminium optic guarantees an high performance.
The ceiling fixing mechanism with double wing steel springs can make the
installation of the lighting fitting very easy; consequently Fly can be used in
false ceilings having a thickness from 1 mm to 30 mm.
Different versions for fluorescent compact and metal halide lamps are
available.
|
|
RECESSED FIXTURE WITH INTERNAL LAMP WITHOUT THE NEED FOR AN OUTER CASING.
|
|
|
PRODUCT FOR SHOPS AND SHOWROOMS, IN METAL AND ALUMINIUM. FRAME IN ALUMINIUM. THE LIGHT SPOTS CAN BE EXTRACTED FROM THE WALLBOX AND ARE ADJUSTABLE TO PERMIT DIFFERENT LIGHTING SITUATION. EACH SPOT HAS A 9 LED CIRCUIT WITH 1W OR 3W LED, LENSES 10° OR 30°
|
|
Semeur d’étoiles manufactures lights. Magical, they are covered with stars (LEDs). LEDs are positioned where you want thanks to a pining connexion technique that require no tool.
Quantity and quality of light can therefore be tuned by adjusting the type and position of "stars", and by adding spots or suspensions.
It makes our lights both decorative and versatile.
Semeur d’étoiles proposes 2 product lines:
- ready-made lights that you just need to hang,
- ceilings/walls that will be installed by you or by a craftsman
|
|
|
These light fittings are designed for mounting into M600 and M625 panel false ceilings with visible holding tracks, into plaster carton and directly on the ceiling. They are designed for T5 (ø16mm) fluorescent lamps. The light fittings are equipped with electronic ballasts by default, but can be also equipped with emergency power supplies (inverters). They can further be equipped with gesis connectors. They are suitable for illuminating common offices and lounges, as well as spaces with high eye work demands.
|
|
|
Ceiling-mounted luminaire GEO for 1 fluorescent lamp 28/54W T16 with base G5, 230V, direct light emission, housing , powder coated white, symmetic reflector, in steel sheet, white, lamella louvre, powder coated white, halogen-free internal wiring, incorporated HF electronic control gear Protection class I, IP20 L = 1190 mm, B = 150 mm, H = 61 mm
|
|
|
|
|
|
TESS Standard Virtual Skylights and Windows
TESS is the ONLY Custom Design Fabricator of backlit Views to Nature™ as virtual windows and virtual skylights, insuring your project will be unique and of the highest quality. With TESS, your Architects can create designs "outside the box."
Our unique circular frame and grid work guarantees more image and less aluminum T-grid because we can also implement pie shaped wedges instead, should you not wish to use light boxes. We also offer multiple choices of custom wood grain finishes for the circular, oval, square or rectangular aluminum grid work
TESS art panels offer realistic Views to Nature™ due to our photo emulsion process ensuring life-like quality, density, distinct contrast and color saturation. TESS art panels will not fade, crack or yellow at ANY light box depth. The integrity of TESS is known throughout the industry for its unique, unequaled product quality, excellent customer service, extensive image library and diverse product applications.
|
|
TESS Standard Virtual Skylights and Windows
TESS Backlit Views to Nature™ in the form of Virtual Windows and Virtual Skylights are specifically designed to meet the goals of the emerging healthcare market's desire to implement evidence-based design within their medical model and the patient's desire for positive, stress reducing distractions which create supportive and spirit based healing environments. TESS backlit Virtual Skylights and Virtual Windows are easy to install and are recognized as a value-added benefit by patients, physicians and facilities as well as leading equipment manufacturers who view them as a complement to their equipment.
|
|
|
The iMod Duet’s unique design encapsulates two (Duet) micro matt louvres and two subtly ribbed clear polycarbonate refractors, creating a module with a clean, contemporary appearance whilst still maintaining exceptional performance. The module boasts impressive technical aspects including an LOR of 0.72 and LG7 compatibility at 70:50:20 reflectances achieving luminance values below 1500cd/m2 at the 65o cut-off. Optional Mars Red, Lava Orange and Acid Green Fluorescent Inserts can be added to the refractors to create a vibrant ‘neon’ edge lit effect and further enhance the versatility of the module.
|
|
|
The Atol combines ambient and accent lighting in a contemporary style. Incorporating energy efficient T5 Fluorescent light sources with a choice of high frequency gear and discreetly etched glass fascias to create a diffused ambience. Versions with die cast Eclipse luminaires have a choice of light sources adding purposeful accent lighting. The range has been designed to offer flexibility to the Designer wishing to co-ordinate lighting environments. Effective and aesthetically stimulating when used in lines or grid patterns in retail premises, galleries or museums.
|
|
- Shallow profile minimally penetrates ceiling.
- Available in semi-recessed or fully recessed versions.
- Extruded aluminum housing and fascia.
- Staggered lamps are standard.
|
|
- Incorporates micro-groove regressed extruded aluminum ceiling trim.
- Offered in 4", 6", and 8" widths.
- Available in T5 or T5HO lamp configurations.
- Only 3 3/8" penetration into ceiling plenum.
|
|
Scrabble gridlights recessed – freedom of configuration
Scrabble MBX500 is a recessed gridlight comprising frames for 1, 2, 3 or 4 adjustable cardanic recessed luminaires for compact discharge and halogen lamps.
A choice of facetted reflectors (12, 36 and 60º) for the compact discharge lamps, plus configurations for the halogen reflector lamps, extends the flexibility in lighting effect even further.
Not available in the UK
|
|
SeneOn recessed system –
play with light SceneOn is a completely modular recessed lighting system for fashion stores and showrooms, consisting of TL5 RGB liminaires, TL5 cool/warm-white luminaires, TL5 louver and TL5 asymmetric luminaires, mini adjustable downlights and even projectors.Featuring integrated lighting controls (DALI and DMX), it can be used in plaster ceilings and suspended ceiling systems.
The SceneOn recessed system lets retailers play with light to create the optimum ambience for their products. It is flexible in use, offering dynamics in lighting level, ...
|
|
Tenno - the merging of light and space
LED developments are driven by miniaturisation and increased performance. In order to
maximise these benefits, innovative lighting solutions are required that can control intensity
and temperature. The use of LED technology within the Vektron ceiling system enables the
possibility to increase the luminaire area and by doing so, improve output and uniformity
whilst ensuring correct operation. Precision optical control and spacing of these individual
LED sources was developed with our partner Bartenbach Lichtlabor.
Tenno has all lighting elements concealed in the tile. There is no competition between
architecture and luminaire, as the two merge together to form an entity. This ensures that light
and space receive the attention they deserve.
Tenno´s innovative solution prepares your room for the future.
|
|
Adding to our popular recessed modular range, ASD’s new Rhapsody Reflector II offers an extended family of lamp and circuit options.
The single or twin central aluminium louvre controls glare and is complemented with perforated wings to create a decorative appearance with a ‘soft style’ of illumination.
This combination provides highly efficient low glare light distribution with both direct and indirect lighting.
Suitable for use with single or twin 40w or 55w TC-L, 2x or 4x 14w T5 and 2x or 4x high output 24w T5 compact fluorescent lamps.
Provided in: High Frequency, High Frequency Emergency and in Digital Dimmable versions options are also available with corridor function.
|
|
This specification grade surface mount is very low profile and features a variety of door and lens options. All metal parts are powder coated white after fabrication.
PM FEATURES
- Low profile, 3-1/2" depth
- Choice of doors from steel to extruded aluminum, open from either side
- Diffuser easily removable for lamp access and cleaning
- Heavy gauge steel housing with embossments for added strength
- Mitered corners
- All parts are powder coated white and painted after fabrication
- Prismatic acrylic lens standard
- Spring loaded steel latches
- Available in pendant mount
- UL listed 1598, cUL or CSA. Damp Location standard
|
|
General
Order code 2831.2G4 alu grey
Mounting Ceiling recessed
Lamps description 2 x TC-D 26w G24d-3
Color Alu grey
Notes HPF on request
Optical
Reflector finish Anodized pure aluminium
Aiming Fixed
Luminous distribution symmetry Symmetric
Downlight symmetry Symmetric
Electrical
Control gear availability Included
Control gear mounting Integral or Remote
Control gear description Conventional with LPF
Emergency Without
Voltage (V) 230
Physical
Place of use Outdoor
Cutout shape Rectangular
Cutout length (mm) 335
Cutout width (mm) 165
Recessed depth 160
Construction materials Corrosion resistant die-cast aluminium
Weight (kg) 4.2
|
|
General
Order code PLATO/N 1/28W
Mounting Ceiling recessed
Lamps description 1 x T16 28w G5
Color White
Optical
Optical system description Louvre
Reflector finish Anodized pure aluminium
Aiming Fixed
LOR (%) 77
Downlight symmetry Symmetric
Uplight symmetry No uplight
Electrical
Control gear availability Included
Control gear mounting Integral
Control gear description Electronic
Emergency Without
Voltage (V) 230
Physical
Place of use Indoor
Ceiling type Module 600
Cutout shape Rectangular
Cutout length (mm) 1196
Cutout width (mm) 296
Recessed depth 55
Construction materials Sheet steel
Weight (kg) 10.1
|
|
|
Complete family of luminaires, in two different designs, and with a wide variety ol models and versions especially designed to (over any illumination project In commercial and industrial areas, offices, learning centres or leisure venues.
|
|
|
Luminaries for mounting or hanging with high quality luminous properties mixed together with high quality design and materials.
|
|
|
The PMC SC12R/14R Series is a direct/indirect recessed fixture, with solid center basket gives softer indirect accent lighting. SC12R/14R fixtures have powder coated housings, with precisionformed, high reflectance, enamel reflectors for optimal optic efficiency. Fixtures are UL listed, and have standard electronic ballasts. Each fixture is lamp-tested at the factory before shipment.
|
|
|
The PMC Perimeter Series are an easy to install, cove lighting and wall washing systems. These fixtures offer superior light out-put, and makes the fixture an interesting when wall mounted, indirect or recessed wall wash light source as well. All perimeter fixtures have gloss white enamel housings, basketry and trim. Fixtures are UL listed, & have standard electronic ballasts. Each fixture is lamp-tested at the factory before shipment.
|
|
The PMC Steel Squares series is one of our most popular lines can be modified with a full range of diffusers and light sources, making it a luminaire to consider for new installations and retro-fit applications.
All fixtures have epoxy powder coated housings, with precision-formed, high reflectance (Minimum Reflectance Factor 90%), enamel reflectors for optimal efficiency. Fixtures are UL listed, and have standard electronic ballasts. Each fixture is lamp-tested at the factory before shipment.
|
|
|
Light diffuses. Typical cove lighting fixtures can create unwanted halo effects. The new P-45i is an advanced design, with an innovative notched back reflector ensuring you of asymmetric indirect light free from socket shadow and ceiling brightness above the fixture. Designed for one or two-lamp T8, T5, T5HO or biax lamps, the P-45i can be mounted within concealed coves, or as an option, it can be surface-mounted and used as its own cove. Standard lengths are two, three, four, six and eight feet. Optimize light into desirable low angles with the new P-45i.
|
|
|
|
|
|
A recessed luminaire with a slim suspended optic which blends upward and downward light for a simple, attractive solution to perfectly balanced office lighting
Provides perfectly balanced illumination of all room surfaces without supplimentary lighting - 30% of horizontal working plane illuminance on ceiling and 50% on walls
The sophisticated optical design provides efficient light output (>60%) with glare control within suitable limits for modern display screens
Fully recessed body with slim profile optic, suspended 82mm below ceiling, minimises intrusion into the room space, making it suitable for low ceilings
Versions available with central louvre or diffuser optics and microperforated side wings in MenloSoft family design, offering a choice of aesthetic appearance and performance options
Supplied with lamps and panel mounted GST male connector for ease and speed of installation, with hinged magnetic optic for easy tool-free maintenance
Available in 600 x 600mm and 300 x 1200mm versions with unique mini-wedge brackets included to allow installation in a wide range of ceiling types and room sizes
Available with High Frequency or digital dimmable control gear for use with lighting controls systems for additional flexibility, with the option of integral mini Sensa head for intelligent luminaires
3 hour emergency and SelfTest emergency versions available as standard
|
|
|
|
