Thanks to the rich offer of profiles, the architects and designers designing enginners may realize even the most bold concepts as regards the aluminium-glass structures. The system is intended for constructing and creating the light-weight curtain walls of hanging and filling type, as well as roofs, skylights and other structures. The shape of mullions and transoms allows building aesthetic facades with visible narrow dividing lines, ensuring the structure durability and resistance at the same time. Additionally, the profiles have rounded external edges, what gives the so-called soft-line effect. The large number of mullions and transoms available in this system guarantees the best possible aluminium use. The economic profiles were obtained by optimization of the intersection shape and by selecting the optimal wall thickness. At a very high load, all mullions may be additionally reinforced with typical internal aluminium profiles, increasing their resistance. The simple profile processing lowers the workload and eliminates all types of carvings at the side surfaces of the mullions.
|
|
|
|
|
|
Slim, constant 52mm sight lines for the mullion and transoms for visual consistency across a project.
A technically advanced framing-system which uses high quality components for long-term durability.
Intelligent design to ensure the quality of fabrication and installation.
A choice of depths up to 240mm for structural members, to meet individual project requirements and ensure cost efficiency.
The options of concealed vents in a variety of configurations.
A range of shaped caps for further design flexibility.
Brise-Soleil solution integration possibilities.
Construction
The mullions and transoms are square cut assembled using a combination of factory fitted face-fixed junction spigots and concealed anti-rotation spigots. This robust construction offers ease of fabrication greater accuracy and enhanced stability.
The mullion jointing uses a specially designed sleeve spigot for each mullion for a quality joint.
All machine operations can be performed on drill jigs with punch tooling for drainage, to reduce fabrication time and cost, and achieve consistent quality.
|
|
Natural beauty
Stabalux Wood is characterized by the aesthetic and purposeful combination of the two materials wood and aluminium. The atmospheric warmth of wood on the inside combined with the resistance and lightness of aluminium on the outside. Technical advantages such as excellent insulating values, various gasket options and a large range of cappings, combine with the natural material of wood to form the optimal unit for architects and building owners.
|
|
Economic solutions for sophisticated glass architecture
The Stabalux threaded tube system, which is made of continuously galvanized steel and integrated screw channel technology, greatly reduces planning, manufacturing and installation costs.
The profiles, which are designed in line with the static requirements, are available in various depths and wall thicknesses, and are ideal for high structures and the creation of a large glazed area look. The threaded tube system is not only suitable for standard glazing but, above all, for special glass types such as fire protection glass and structural glazing.
|
|
|
Stabalux T-profiles for steel-glass structures stand out from conventional sections due to the sharpness and clarity of their form. Narrow face widths and various section dimensions are created in line with the current architectural focus on clear and exacting designs. Add-on sections with exact gasket and screw location technology, transform the Stabalux T-sections into excellent glazing systems.
|
|
|
YKK AP is concerned about our environment and is constantly developing new systems to meet the LEED requirements of the US Green Building Council. YKK AP%u2019s ThermaShade%u2122 system is designed to improve tenant comfort and lower energy consumption by decreasing solar heat gain. This system offers a wide spectrum of design options and is available in both anodized and all YKK AP standard or premium paint colors.
|
|
|
|
|
|
Elegance 52 is a comprehensive curtain wall system that combines technology and design with the demands of contemporary building architecture and construction. All Elegance 52 systems use a common substructure with a width of 52 mm, allowing a slim sightline, whilst maintaining the necessary strength and inertia requirements. Weather performance, thermal insulation, building connection, ease of fabrication and installation were the key factors that influenced the design of Elegance 52.
Elegance 52 is available in 6 variants, each providing unique design features:
- Elegance 52 ST (standard)
- Elegance 52 HL (horizontal lining)
- Elegance 52 SGV (structural glazed vent)
- Elegance 52 SG (structural glazed frame)
- Elegance 52 GF (glazed frame)
- Elegance 52 SX (structural glazing)
- Elegance 52 can be used in vertical, sloped or roof applications
- May be connected to other levels of curtain walling and building materials
- Weather performance tested to CWCT standards
- Fully integrated with other Sapa Building Systems product ranges, thus delivering a complete façade solution
|
|
This new system has been designed for the construction of stick walls with external capping, to manufacture vertical and straight, facades or skylights (as an alternative to the SL60 system] that allows the manufacturer to save in terms of the weight of the product and labor expenses.
The series is formed by sections characterized by the overall front dimensions of 50mm that still maintains the static features ideal for the high floor to floor distance and capacity loads. Two new thermal break profiles (outer and inner frames] are available for the open-able part of the structure either in structural glazing or with mechanical retain of the glass
|
|
Systems of profiled out of aluminum for curtain wall with Stuck External Glazing or Panel strong Points
- Frontage with structural glazing without cap
- Perfectly plane and homogeneous Surface (joined hollow 20 mm)
- Integrated system of window opening hidden towards outside
- Maximum Sealing and soundproofing with joints EPDM
- Clips of security
- Diversity of mullions
Manufacture, installation
- High Limits of size of a panel 870 X 1500 mm (L X H)
- Profiled mullions and cross-pieces bonded according to percussion principle
- Glazing structurally stuck to an anodic section located in opening
- Profiled gone up to the moeyn of clamps with eccentrics or to crimp
- Panels installed and fixed using parts of connection
|
|
Designs with an exclusive touch
The scope of creative facade design is considerably enlarged by our varied range of exclusive special pieces. In addition to the standard sizes, the rectangular tube and the 3D profile are also available in lengths of up to 1.20 m, which can be combined with all facade systems. They can be combined with all facade systems.
Whether strictly angular or softly rounded: both categories of forms can be realized in numerous variations. In this way, external corners, embrasures and other projections can be integrated in a visually harmonious manner and safely executed with regard to construction physics. Tensions due to extreme changes in temperature, which may occur in the case of facades made of different building materials, are avoided.
|
|
TERRART® Baguette are ceramic pipes with square, circular or oblong cross-sections, which can also be made as curved elements or as double baguettes on request.
A suspended façade construction that is ventilated at the rear offers an ideal way to implement aesthetically suitable and modern architecture.
NBK Ceramic has a comprehensive TERRART® product line, which is adapted to individual specifications and suits the special wishes of customers.
The special TERRART® Flex substructure system offers the flexible basis for almost limitless possibilities.
|
|
|
|
|
|
Teckentrup Tubular Profile Doors
Protection and transparency perfectly combined
In addition to the solid steel plate fire and smoke protection doors, Teckentrup offers a flexible steel, stainless steel and aluminium tubular profile system for modern, light-oriented architectural concepts which is combined with large-scale glazing elements.
The flexible system, numerous safety functions, innovative features and a wide range of designs ensure individual fulfilment of all building requirements. Light-efficient designs for buildings: Whether in family homes, residential complexes, industrial companies and administration buildings, nursing homes, kindergartens, schools or car parks, Teckentrup tubular profile systems combine specified safety standards with visual perfection.
• Made of steel, stainless steel or aluminium
• Available as T30 and T90 version
• Single and double leaf version
• Optionally with upper casing and side part
• Also available as glazing wall
• Tested in accordance with DIN 4102
|
|
|
The breadth and depth of the Arval range of profi les brings together traditional and timeless shapeswith new and innovative alternatives : - Smooth HAIRPLAN and ST strips - OCEANE clapboards range - FREQUENCE range - TRAPEZA profi les range. Made from steel coated according to Colorissime or in stainless steel. The implementation of this wide range of systems, may be excitingly combined with the imagination of the architect, to bring life and originality to the façade.
|
|
|
The breadth and depth of the Arval range of profi les brings together traditional and timeless shapeswith new and innovative alternatives : - Smooth HAIRPLAN and ST strips - OCEANE clapboards range - FREQUENCE range - TRAPEZA profi les range. Made from steel coated according to Colorissime or in stainless steel. The implementation of this wide range of systems, may be excitingly combined with the imagination of the architect, to bring life and originality to the façade.
|
|
|
With the density of its shapes, Baïne enhances façades and roofs with a world of creativity and thought. The sinusoidal-wave profile in stainless steel, coated steel, or aluminium can integrate fl at facing to lighten the interpretation of the building
|
|
CLIX cladding panel has a unique fixing principle, and is therefore one of the most rational and easily fitted building plate systems on the market. CLIX panels have NO LOOSE componen or CLEAT's and so that allows to safe more then 70 present times (cost) on erecting work and gives to the contractors and private customers excellent logistic and price inside EU. CLIX cladding panels is aesthetically appealing and as a modern building plate system it is maintenance-free with a very long useful life. The development work has taken more than ten years from concept to the finished, patented and tested product, which has also been type-approved by SITAC.
Material : Titanzinc, ALUZINC, Copper, Aluminium
Effective width : 475 mm,
Maximum length: 12500 mm; Minimum length 1850 mm,
Height of joint : 35 mm,
Thickness : 0,5 - 0,7 mm; Sales unit m2,
Delivered direct from the manufacturers ( Sweden) in 3 weeks after order.
|
|
|
S Profile is perhaps the oldest established corrugated profile and it is described and defined in BS 4868. This is a very shallow profile and is therefore not suitable for foot traffic, but is intended for close spaced purlins on relatively steep pitches. Since this is a symmetrical profile it is suitable for forming into smooth curves.
|
|
|
|
