Visual fire detector operating on the principle of scatter, operating voltage: 8-28V, alarm current: 9,2mA, protective system: IP 40, colour white with red D+H-Logo, with individual display in case of alarm, VdS-approval number: G29226
|
|
The detector base E1000BREL12NL is used together
with the optical smoke detector ORM1003 for early
detection of fire in buildings.
The detector base can be connected to 12 V intruder
zones, e.g. zone terminals MT/S 4.12.1 and MT/U
2.12.1. The supply voltage is 12 V DC. A floating twoway
contact serves as an alarm output. An optional
reed relay RL in the last detector of the zone monitors
the supply voltage and the removal of a smoke detector
from the base. For testing the detector, a testing
aerosol or a remote test unit can be used.
|
|
The ATH Sec DH detector is an optical/thermal multiple sensor that uses digital thermal technology, integrating an optical camera to increase the volume of smoke analysed.
It recognises sharp increases in temperature and changes the optical camera's sensitivity accordingly. It detects fast-burning fires with flames as well as surface or flameless fires.
The optical camera is protected by a rustproof metal membrane.
|
|
Optical smoke detector OP320C
The OP320C is the absolute all-rounder in the Synova product range. It has a completely new and patented optical system and the latest electronics. This opens up new dimensions in the level of safety and functionality.
|
|
WWS4916 Wireless Photoelectric Smoke Detector
-Low profile design
Automatic drift compensation
High/Low sensitivity reporting
Built-in, dual-sensor heat detector
135 °F (57 °C)
Easy-maintenance removable chamber
Local test button
Built-in 85 dB horn
Non-contact sensitivity testing
with FSD-100 test-meter
UL listed 268 / ULC listed S531
for residential applications
|
|
|
|
|
|
ESL 320A/350 Series alarms are single/multiple station photoelectric AC smoke alarms designed for use in residential occupancies, including hotels, motels, and dormitories. The 320A/350 Series is compatible with existing ESL 320 Series wiring and up to twelve units may be interconnected for tandem operation. When any unit in tandem senses smoke, all the units sound an alarm.
The ESL 320A/350 Series features a test/silence button on the front of the alarm that facilitates testing. The series continuously monitors its own sensitivity; and if the alarm falls out of sensitivity, ESL's proprietary field replaceable optical chamber enables quick and easy cleaning and maintenance. The series meets NFPA 72 field sensitivity requirements without the need for external meters.
The 350 Series provides a battery backup that offers up to 46 hours continuous protection in the event of a power outage. Other models provide auxiliary relay options.
All models are photoelectric alarms, which detect smoldering fire faster than the more common ionization alarms. Since smoldering fire is one of the most preva-lent types of residential fires, photoelectric alarms are essential in these applications.
|
|
The ESL 500N series two- and four-wire conventional photoelectric smoke detectors bring together trusted technology and a full line of features to meet the demands of every type of application. The 500N offers sounder models in two- and four-wire applications, specifically
to meet residential code requirements. The 521NCSXT has the
additional benefit of low current draw which makes it compatible with a wide variety of control panels. The ESL 500N series also offers choices for optional auxiliary relays and isolated heat sensors, not available before in the ESL 500 series. ESL offers CleanMe®, dust compensation, field replaceable optical chambers, multiple criteria heat algorithms, and self-diagnostics features.
|
|
Prevention sets fire to in a flat extra design.
The discrete and elegant bpîtier agrees with a modern architecture and is integrated into all the interiors. Setting in radio operator network intelligent on 868 MHz - without posing cables. For a maximum security since all the smoke detectors put in radio operator network start alarm and thus announce at once a possible appearance of smoke, even in a part located at the variation.
|
|
Functional description:
The autonomous smoke detector detects the fires with slow progression. It is adapted to the protector of the privative parts of the buildings or residences of dwellings.
Food by alkaline pile 9 volts.
Technical description:
Autonomous detector
|
|
