Electric towel radiator Manava

hot water501 w...750 w0...500 w

Overview
Heated towel radiator for central heating with an elegant, original design. Provides uniform heat distribution to warm the bathroom and towels. Customisable in 46 colours and two hammered finishes. High-quality steel protected by an anti-corrosion treatment, finished with an epoxy/polyester powder coat. Base colour: Traffic White (RAL 9016). Available in central-heating and electric versions. Made in the European Union.

Key features

• Comfort: Provides uniform heat distribution to warm the bathroom and towels
• Design: Original contemporary style
• Customisation: Available in 46 colours and two hammered finishes
• Durability: Steel protected by anti-corrosion treatment, long-lasting powder coating over the whole surface
• Practicality: Multiple sizes available, double version for higher output, design facilitates towel placement

Description

• Heated towel radiator in steel
• Round horizontal tubes Ø 20 mm, single or double thickness, welded to vertical collectors Ø 30 mm
• Anti-corrosion protection by cataphoretic dip
• Finish by epoxy/polyester powder coating
• Base colour: Traffic White (RAL 9016)
• Optional: available in the 46 colours of the Acova swatch

Wall projection
100 mm

Number, type and diameter of connections

• Bottom feed with 50 mm centres
• 2 connections 1/2’’ at the ends of each collector
• Supplied with H-shaped angled valve and right-hand manual head

Models and references
Reference | Central heating power Δ50 (W) | Height (mm) | Width (mm) | Net weight (Kg) | Price excl. VAT (€)
WMVSS090060WZZZ | 360 | 908 | 600 | 9.60 | 590.00
WMVSS130050WZZZ | 477 | 1340 | 500 | 12.80 | 620.00
WMVSS130060WZZZ | 541 | 1340 | 600 | 14.30 | 630.00
WMVSS180050WZZZ | 621 | 1772 | 500 | 17.00 | 720.00
WMVSS180060WZZZ | 706 | 1772 | 600 | 19.00 | 730.00

Available documents
Product sheet, Installation manual, Price guide, Colour chart, DOP, Environmental characteristics

Characteristics / technical specifications

• Material: steel
• Round horizontal tubes Ø 20 mm; vertical collectors Ø 30 mm
• Options: single or double tube thickness (single or double versions)
• Anti-corrosion treatment: cataphoretic dip
• Finish: epoxy/polyester powder coating
• Base colour: Traffic White (RAL 9016); available in 46 colours and 2 hammered finishes
• Projection: 100 mm
• Feed: bottom feed, 50 mm centres
• Connections: 2 connections 1/2'' at the ends of each collector
• Supplied accessories: H-shaped angled valve and right-hand manual head
• Manufacture: European Union
