LED strip light ACTITUBE40E

IP66polycarbonateopal

The ACTiTube40E is a versatile lighting solution engineered to meet the most demanding requirements of the industrial and commercial sectors. Combining a compact design with extreme durability, it delivers uniform lighting—perfect for workstations, technical zones, and high-traffic areas.
Certified "Origine France Garantie," this luminaire stands out for its direct 230V connection with no external driver, significantly streamlining installation and long-term maintenance.

Product Highlights

• Performance & Durability: Reinforced waterproof rating (IP66) and maximum impact resistance (IK10).
• Visual Comfort: Homogeneous luminous flux (3,567 lm/m) with zero dark spots across the entire length of the tube.
• Simplified Installation: Direct 230VAC power supply (driverless) with an optional through-wiring feature for daisy-chaining.
• Easy Maintenance: Smooth surface and resilient materials for quick, efficient cleaning.

Applications

• Industrial: Machine tools, assembly lines, logistics hubs, and technical rooms.
• Commercial & Public Spaces: Lobbies, corridors, office spaces, and underground parking garages.

Technical Specifications

• Dimensions: Ø 40 mm
• Luminous Flux: 3,567 lm / meter
• Power Consumption: 20W/m or 33W/m
• Energy Efficiency: Power factor 0.98
• Color Rendering Index (CRI): > 84
• Service Life: 50,000 hours (L90B10)
• Color Temperature: 4000K (Neutral White) or 5000K (Cool White)
• Dimming: Phase-cut dimmable

Design & Materials

• Housing: High-resistance, UV-stabilized polycarbonate tube (Clear or Opal finish).
• Sealing: Elastomer (SEBS) end caps ensuring long-lasting protection against fluids and dust.
• Safety: Class II.

Installation & Customization

• Mounting: Stainless steel clips or magnetic brackets for total on-site flexibility.
• Connectivity: Supplied with 2m of cable (2 x 0.75 mm²). Custom cable lengths available upon request.
• Options: Linkable version for continuous series installation.

Quality Commitment: A compact, lightweight luminaire, developed and manufactured in France for uncompromising industrial reliability.
