LED strip light ACTITUBE40S

IP68IP66stainless steel

The ACTiTube40S by ACTiLED is a versatile and robust lighting solution designed to meet the most demanding requirements of architectural and commercial projects. Combining a compact form factor with high performance, it showcases French manufacturing excellence, certified by the "Origine France Garantie" label.
The ACTiTube40S embodies local industrial expertise. Selecting this luminaire ensures exemplary traceability, an optimized carbon footprint, and support for French technological innovation.

Key Applications

• Architecture & Exterior: Facade lighting, pathway marking, and decorative staging.
• Commercial & Industrial: Offices, lobbies, common areas, technical rooms, and parking facilities.

Technical Advantages

• Simplified Installation: Direct 230V connection without the need for an external driver, saving installation time and increasing overall reliability.
• Extreme Durability: IP66/IP68 ingress protection and IK10 impact resistance. The 316L stainless steel end caps ensure maximum longevity, even in corrosive environments.
• Light Quality: Homogeneous diffusion along the entire length of the tube. Also available with a 20° concentrated beam for precise directional lighting.
• Modularity: Linkable version with through-wiring available for creating continuous light lines.
• Easy Maintenance: Smooth surface for quick and efficient cleaning.

Technical Specifications

• Dimensions : Diameter 40 mm / Lengths from 40 to 180 cm
• Luminous Flux : Up to 3,567 lm/m (Opal, 4000K)
• Energy Efficiency : Power Factor: 0.98Lifespan50,000 h (L90B10)
• Materials : UV-treated polycarbonate, 316L Stainless Steel
• Dimming : Phase-cut (Triac)
• Color Temperatures : 2700K, 3000K, 4000K, 5000K

Finishes & Customization

• Optics: Clear or opal polycarbonate diffusers.
• Color Options: Integration of colored gels within the tube for bespoke lighting atmospheres.
• Mounting Systems: High-resistance stainless steel clamps with optional anti-vandal screws for public spaces.
• Bespoke Wiring: Custom cabling options (e.g., 2x1.5mm²) tailored to your specific site constraints.
