APPLICATION
Urban LED lighting luminaire
MECHANICAL CHARACTERISTICS
Heat-sink in extruded aluminium. Powder painted.
Gasket in polyurethane.
Screen: flat tempered glass high transparency.
Removable metal gear plate.
Cable gland plastic, M20x1,5 – IP68 Total
Protection degree IP66 | IK08
Operating temperature: - 40°C + 50°C
Weight and dimensions:
MOD 2.0 BOLLARD 500: 250x100 11kg
MOD 2.0 BOLLARD 1000: 250x100 19kg
Colour (powder coating):
Graphite 01
Silver 03
Corten 3B
Other colors on request.
Corrosion protection:
1500hr saline fog ISO 9227.
ELECTRICAL CHARACTERISTICS
Insulation class: I, II.
Power supply: 220-240V - 50/60Hz.
LED current: 350mA
Inrush current: max. 62A pk (th = 330 μs)
Power factor:
> 0.9 (at full load).
For cables sec. max 4 mm2 (versions with on-load switch).
Outgoing cable: H07RN-F 2/3x1.5mm2 with connector IP68.
