Window automation S/P

for doorswing

Description
The S/P operator, designed to operate glass doors and windows, combines aesthetic design and functionality; its compact footprint provides high installation versatility. This model is especially suitable for direct mounting on the sash when there is insufficient space above the frame. Movement is smooth and silent, with the ability to stop the sash at any position; manual operation is available in case of emergency.

Features

• Consists of a 230 V gearmotor with maintenance-free steel mechanics, assembled inside an extruded pre-painted aluminium housing.
• Mechanical safety clutch to protect the operator against overloads.
• All steel components treated with anti-corrosion coating.
• Monobloc supporting structure, ready for installation.
• The operator becomes reversible when the sash is pushed manually exceeding a torque of 90 Nm.
• Emergency manual operation possible; for prolonged manual use loosen the clutch adjustment screws to release the sash completely.

Control units

• Synchronized with C/C control unit in automatic mode: allows opening and closing a single unit or all units simultaneously via centralized command; a RX2 radio receiver with remote control can be paired to the C/C unit.
• Synchronized with DP1 control unit with 'man present' command.
• Separated operation with two double 'man present' pushbuttons.

Electric lock
The hook-type electric lock G/E (available on request) increases closing security against possible external tampering.

Integrability
The operators can be integrated with home automation systems. They can also be connected to UPS units to keep the system running during power outages.

Technical data
Power supply: 230 V 50 Hz
Current consumption: 0.45 A
Torque: 42 Nm
Operating time for 180°: 13 s
Max irreversibility torque: 90 Nm
Noise level: 33 dB
Service cycle: 20 %

Features / technical specifications

• Power supply: 230 V 50 Hz
• Current consumption: 0.45 A
• Rated torque: 42 Nm
• Max irreversibility torque: 90 Nm
• Operating time for 180°: 13 seconds
• Noise level: 33 dB
• Service: 20 % (duty cycle)
• Gearmotor with maintenance-free steel mechanics
• Extruded pre-painted aluminium housing
• Braking/friction mechanism for safety and manual operation management
• Steel components treated against corrosion
