Sliding sectional garage door S/BG

steelextruded aluminumpre-coated aluminum

Overview
The Serratore S/BG is an automation unit for garage doors designed for easy installation on existing doors without altering walls or leaves. It provides smooth, quiet operation with a full 180° opening; in specific cases two different opening angles can be configured.

Main features

• Single-piece supporting construction, supplied to the required dimension and ready for installation.
• Two 230 V gear motors with maintenance-free steel mechanics, assembled in a pre-painted extruded aluminium housing.
• Mechanical safety clutch to protect against overloads and wind gusts.
• All steel components treated with anti-corrosion protection.
• Single cable entry for a simple and tidy electrical installation.

Customization
The Serratore can be customized for different hinge types and door leaf configurations according to installation needs.

Control units
Operation can be managed with commercial control units for two motors, radio controls, photocells and similar accessories.

Electric locks
On request electric locks are available to increase closing retention: offered with internal hook (G/I, assembled inside the housing) or external fixing hook on the leaf (G/E).

Release handle
An emergency release handle is available for opening and closing the door in case of emergency, usable from both inside and outside.

Integrability
The automation can be integrated with home automation systems and connected to uninterruptible power supplies (UPS) to keep the system operational during mains power loss.

Technical specifications

• Power supply: 230 V 50 Hz
• Current consumption: 0.80 A
• Torque: 80 Nm
• Operating time for 180°: 23 s
• Maximum irreversible torque: 150 Nm
• Duty cycle: 13 %
