Fiberglass reinforcement grid POLITES AR 250

protectivefor flooringfor masonry

Short description
AR alkali-resistant fibreglass mesh for reinforcement of the underside of floor slabs in anti-shuttering and anti-cracking systems. Installed with steel fixing components.

Features
AR fibreglass mesh designed to address crumbling of floor slab undersides in masonry and steel-concrete slabs. Installed using dedicated steel fasteners (screws, dowels, flanges). Alkali-resistant. Intended for use with Diathonite Thermactive.037 or Diathonite Acoustix. Contains zirconium dioxide (>16%). Manufactured in leno weave.

Yield
1.1 m2/m2. Ensure an overlap of at least 10 cm between adjacent sheets/netting.

Application
For incorporation in anti-cracking and anti-shuttering reinforcement systems. Refer to the Technical Data Sheet for recommended installation procedures and substrate preparation.

Packaging
Roll: 1 × 50 m. Pallet: 550 m2 (11 rolls).

Drying
No drying required.

Benefits

• Fast and easy to install;
• Lightweight and low thickness;
• Excellent mechanical properties in warp and weft;
• Weathering resistance;
• Easy to cut;
• Manageable on site and straightforward to apply;
• Suitable for use in aggressive environments;
• Durability;
• Compatible with all common substrates;
• Non-flammable;

Technical data
Yield: 1.1 m2/m2
Colour: red
Mesh pattern: leno weave appearance
AR glass fibre: alkali-resistant composition
Mesh width (UNI 9311/2): 25×25 mm
Dressed fabric weight (UNI 9311/4): 280 g/m2 (dressed)
Raw fabric weight: 182 g/m2
Average thickness of dressed fabric: 1.10 ± 5% mm
Application temperature: +1 / +35 °C
Drying time (T=23°C; R.H. 50%): no drying required
Number of threads Warp: 38
Number of threads Weft: 38
Packaging roll: 1×50 m
Equivalent thickness (warp): 0.0522 ± 5% mm
Equivalent thickness (weft): 0.0522 ± 5% mm

Technical specifications

• Product: AR alkali-resistant fibreglass mesh for floor slab underside reinforcement
• Yield: 1.1 m2/m2
• Colour: red
• Mesh width: 25×25 mm (UNI 9311/2)
• Dressed fabric weight: 280 g/m2 (UNI 9311/4)
• Raw fabric weight: 182 g/m2
• Average dressed fabric thickness: 1.10 ± 5% mm
• Equivalent thickness (warp/weft): 0.0522 ± 5% mm
• Number of threads: Warp 38, Weft 38
• Contains zirconium dioxide: >16%
• Application temperature range: +1 / +35 °C
• Drying: no drying required (T=23°C; R.H. 50%)
• Packaging: roll 1×50 m; pallet 550 m2 (11 rolls)
