Aluminum roof window DEG P2 Z-WAVE

glassuPVCfixed

Overview The DEG P2 Z-Wave is a fixed electrically operated flat roof window designed to provide natural daylight with high thermal and acoustic performance. It features a P2 glazing unit with an internal P2A laminated pane and an external toughened pane, plus a white printed glass segment for an architectural finish. Z-Wave wireless control, power supply and rain sensor are included for automated and remote operation.

Key benefits and functions

• High thermal insulation: Uw = 0.92 W/m²K; acoustic insulation Rw = 36 dB.
• Wireless Z-Wave control compatible with remote controls, wall switches and home automation gateways.
• Electric actuator (ZWS12) with sash travel up to 120 mm for controlled ventilation.
• Integrated rain sensor (ZRD) triggers automatic closure on rainfall.
• Flat glass segment in white (RAL 9010) and black external aluminium cladding (RAL 9005) for a minimalist appearance.
• Suitable for flat roof installations with pitch from 2° to 15° (0° possible with XRD/A frame; references also 5°–15°).
• Standard kit includes one electric actuator, rain sensor and power supply.

Product details / technical highlights

• Glazing: single-chamber P2 unit (internal P2A laminated glass, external toughened glass).
• Thermal performance: Uw = 0.92 W/m²K.
• Airtightness: Class 4.
• Wind load resistance: Class C5/B5.
• Impact resistance: Class 5 (950 mm).
• Watertightness: E1200.
• Acoustic insulation: Rw = 36 dB.
• Number of seals: 3.

Installation, compatibility and appearance

• Commercial size (W × H): 60 × 60 cm (selected size).
• External finish: black cladding RAL 9005; internal finish: white printed segment RAL 9010 / white PVC profiles.
• Frame: multi-chamber uPVC profile with insulating fill, moisture-resistant.
• Optional installation bases (XRD, XRD/W) for green, gravel or ventilated roofs; XRD/A frame enables 0° installations in specific setups.

Actuator and sensors

• Actuator: ZWS12 electric drive (Z-Wave) — remote and wall-switch operation; sash travel up to 120 mm.
• Rain sensor: ZRD mounted on sash for automatic closure on rain; operates without user programming.
• Power supply: included in the kit.

Set contents and accessories

• Standard set: window with P2 glazing, electric actuator (ZWS12), rain sensor, power supply.
• Recommended accessories (optional): internal blinds (ARF-D, ARF-D NE Z-Wave), external shutters (ARZ Komfort Z-Wave Solar).

Technical specifications

• Commercial name: DEG P2 Z-Wave
• Commercial size (W × H): 60 × 60 cm
• External frame width: 820 mm
• External frame height: 820 mm
• Window frame clear opening width: 517 mm
• Window frame clear opening height: 517 mm
• Window sash clear opening width: 476 mm
• Window sash clear opening height: 476 mm
• Window reveal clear opening width: 558 mm
• Window reveal clear opening height: 558 mm
• Interior colour: PVC white (RAL 9010)
• External cladding colour: Black RAL 9005
• Window material: multi-chamber uPVC profile
• Control system: Z-Wave control
• Installed electric control: ZWS12 actuator
• Solar power supply: No
• Number of actuators: 1 electric
• Set contents: Rain sensor, Electric actuator, Power supply
• Number of seals: 3
• Thermal transmittance Uw: 0.92 W/m²K
• Airtightness class: Class 4
• Wind load resistance: Class C5/B5
• Impact resistance: Class 5 — 950 mm
• Watertightness: E1200
• Walk-on window (Walk On): No
• Acoustic insulation Rw: 36 dB
• Roof pitch (min.–max.): 2° – 15° (0° possible with XRD/A frame)
• Product weight: 40 kg
• Package width: 0.91 m
• Package length: 0.92 m
• Package height: 0.28 m
