PVC dome skylight DXF DU6

glasstemperedfor flat roofs

Overview
The DXF DU6 by FAKRO is a non-opening flat roof window engineered to maximise natural daylight while providing high thermal performance. The flat glass offers a minimalist appearance suited to contemporary architecture and interior design. Compared with standard solutions, the glazed area can increase by up to 16%, enhancing interior brightness.

Key benefits

• Up to 16% more glazing area vs standard units for improved daylighting
• Excellent thermal insulation: Uw = 0.7 W/m²K (selected 60×60 size)
• Fixed, non-opening design for optimal airtightness and reduced maintenance
• Multi-chamber uPVC profiles filled with insulating material for durability
• DU6 double-chamber glazing with P2A laminated inner pane for safety and toughened outer pane with hail-resistance warranty
• Compatible with flat roofs pitched 2°–15°; installable on XRD, XRD/W or XRD-A bases when required
• Optional internal accessories and external awning blinds to control solar gain

Glass & glazing
The product is supplied with the DU6 glazing unit — a double-chamber assembly delivering strong thermal performance. The inner pane is laminated (P2A) to limit risk of fall-through after breakage; the outer pane is toughened and covered by a lifetime hail-resistance warranty.

Frame & material
The frame uses white multi-chamber uPVC profiles (RAL 9010) filled with insulating material to resist moisture, cleaning agents and temperature changes. External cladding is black (RAL 9005). The construction is maintenance-free and designed for long-term performance.

Installation, control & suitability

• Suitable for flat roofs with pitches from 2° to 15°
• For pitches below 2° or to increase the installation angle use the XRD-A angled base
• For green, gravel or ventilated roofs use XRD or XRD/W bases to raise the window above finishing layers and ensure drainage
• Non-opening configuration — no electric control, no solar power supply and no remote control in standard version

Maintenance and durability
The DXF DU6 is designed to withstand external factors such as moisture, corrosion and temperature variation. Multi-chamber profiles and robust glazing provide long-lasting functionality and appearance even under heavy rain or strong sunlight.

Technical specifications

• Model: DXF DU6
• Brand: FAKRO
• Type: Flat roof window, Type F (glued glazing unit)
• Commercial size (W × H): 60×60 cm
• External frame width: 820 mm
• External frame height: 820 mm
• Window frame clear opening (W × H): 517 mm × 517 mm
• Window sash clear opening (W × H): 476 mm × 476 mm
• Window reveal clear opening (W × H): 558 mm × 558 mm
• Glazing unit: DU6 double-chamber; inner laminated glass class P2A; outer toughened glass
• Heat transfer coefficient Uw: 0.7 W/m²K (selected 60×60 size)
• Number of seals: 1
• Airtightness (air permeability): Class 4
• Wind load resistance: Class C5/B5
• Impact resistance: Class 5 – 950 mm
• Watertightness: E1200
• Acoustic insulation Rw: 34 dB
• Walk-on window: No
• Control system: Non-opening
• Solar power supply (standard): No
• Installed electric control (standard): No
• Remote control (standard): No
• Window material / frame colour: multi-chamber uPVC profile, PVC white (RAL 9010)
• External cladding colour: Black (RAL 9005)
• Product weight: 42 kg
• Package dimensions (W × L × H): 0.91 m × 0.92 m × 0.28 m
• Item number (logistics): 80CC01
