Polycarbonate dome skylight DEC-C P2 Z-WAVE

PVCtemperedfor flat roofs

Overview
Designed for maximum user comfort, the DEC-C P2 Z-Wave is an electrically operated flat roof window dedicated to rooms where providing natural daylight, structural tightness and durability are priorities. The transparent dome and selected glazing brighten spaces without traditional light sources and improve interior comfort.

Electric control and rain protection
The window features an electric opening option controlled via Z-Wave radio technology, allowing wireless integration with Smart Home systems through a dedicated gateway. The set includes a power supply unit and a rain sensor that automatically closes the window when rain is detected. Control can be performed by a wall switch and remote control; the actuator allows sash tilt up to 120 mm for effective ventilation.

Dome
The dome is made of transparent polycarbonate, highly resistant to impact and weather. Its transparency provides effective interior lighting while protective coatings reduce UV transmission and enhance long-term aesthetic durability.

Glazing unit P2
The single-chamber P2 glazing unit features an internal P2A laminated glass for basic protection against forced entry and an external toughened glass covered by a lifetime hail resistance warranty. The glazing contributes to a heat transfer coefficient of 1.2 W/m²K (for the selected size).

Actuator
The integrated electric actuator (ZWS12) operating in Z-Wave technology enables comfortable remote operation via remote control or wall switch. The mechanism is durable and designed for long service life; it enables integration with home automation and provides convenient ventilation control.

Rain sensor
The ZRD rain sensor mounted on the sash sends a signal to the actuator when rainfall is detected, triggering automatic closure of the window. The sensor operates automatically and helps protect the interior even when the building is unattended.

Key features

• Heat transfer coefficient Uw = 1.2 W/m²K (selected size)
• Transparent polycarbonate dome
• Suitable for installation on pitches from 0° to 15°
• Wirelessly controlled via Z-Wave (remote control integration)

Technical specifications

• Model: DEC-C P2 Z-Wave
• Brand: FAKRO
• Commercial size (W × H): 60 x 60 cm
• External frame width: 820 mm
• External frame height: 820 mm
• Window frame clear opening width: 517 mm
• Window frame clear opening height: 517 mm
• Window sash clear opening width: 476 mm
• Window sash clear opening height: 476 mm
• Window reveal clear opening width: 558 mm
• Window reveal clear opening height: 558 mm
• Heat transfer coefficient (Uw): 1.2 W/m²K
• Glazing: single-chamber P2 (internal P2A laminated, external toughened glass)
• Dome material: transparent polycarbonate with protective coatings
• Suitable roof pitch: 0°–15° (compatible with XRD and XRD/W installation bases for raised installation)
• Control system: Z-Wave wireless control
• Installed electric control (actuator): ZWS12
• Solar power supply: No
• Remote control: No (actuator supports remote operation when additional remote provided)
• Number of actuators: 1 electric
• Set contents: Rain sensor, Electric actuator (power supply included)
• Number of seals: 3
• Airtightness (air permeability): Class 4
• Watertightness: Compliant
• Acoustic insulation Rw: 35 dB
• Walk-on window (Walk On): No
• Window colour / appearance: PVC white (multi-chamber uPVC profiles)
• Window material: multi-chamber uPVC profile filled with insulating material
• Product weight: 37 kg
• Package dimensions (W × L × H): 0.91 m × 0.92 m × 0.37 m
