Geotechnical calculation software STRATIGRAPHY – CROSS SECTIONS

for steel structures3D

The Stratigraphy - Cross Sections module is designed for easy creation of geological cross-sections (including lenses, faults). It provides scaled outputs of the cross-section with field tests and soil profiles. No CAD program is needed. For geological data reporting from site investigation results use Stratigraphy - Logs module. The modules are extensions of the Stratigraphy program. Stratigraphy program with Logs and Cross Sections modules are available in the “Geology package” for 1,500 € ($1,700). Main Features Straight or polyline shape of cross sections Viewing of selected field tests and soil profiles Easy input of interfaces between layers Creation of faults and lenses Definition of the geotechnical soil types and groups Input of different ground water levels Drawings of structures, auxiliary lines and user´s descriptions Different scaled outputs in both directions Possibility to display field test results or user-defined data for each layer Data preparation for 3D geological model Cross section export to PDF, DXF, DWG formats No CAD program is needed
