Stainless steel expansion joint JDH 6.26

stainless steelaluminumstainless steel

Special flexible floors For joint gaps from 50 to 200 mm Seismic floor expansion joint for large movements, comprising the side angle sections and a central plate made of stainless steel, able to take up expansion and contraction movements, as well as vertical shearing movements. . Suitable for all types of finish: concrete, screed, tiling, etc. For indoor and outdoor floor joints with a gap up to 200 mm (please enquire if more width is required), with large amount of movements. JDH 6.26 joints are particularly suitable for hospitals, schools, etc. Suitable for intense pedestrians and light trolleys traffic. Section length of 3 lm. Stainless steel side angle sections and middle plate. Floor-to-floor Series JDH 6.26 , and floor-to-wall Series JDH 6.26 A Anti-slip ribbed stainless steel. Waterproof membrane as option, with possibility of integrating drainage system to recover the liquid. JDH 6.24 joints can be matched to vertical joints in terms of finish and movement range (please enquire). All metal seismic floor expansion joint interior special flexible flooring or 3mm carpet finishings.
