stainless steel cladding / textured / mesh / metal look



  • Material:

    stainless steel

  • Finish:


  • Configuration:


  • Appearance:

    metal look, translucent

  • Other characteristics:

    for ventilated facades, durable, incombustible, custom


Weight: appr. 7,3 kg/m² (1,50 lbs/sqft)
Open area: appr. 58%
Main applications: Façade, Ceiling, Wall, Balustrade

• Good stability due the rectangular opening and the utilized wires.

• The flat surface on one side of the EGLA-MONO creates a reflection across the full plane.

• Very robust mesh.

• Used for a wide range of applications due to its rigidity.

All architectural meshes are specially manufactured for each individual project. The maximum width of the mesh is 3 m. The length is up to 30 m and can be flexibly adapted to the project.
