Water pump e-SVI

electricmetal

Overview
The e-SVI series CAD center provides downloadable CAD and BIM files for e-SVI speed variators/gearmotors in multiple sizes and power ratings. Listings include available versions, nominal powers and the document formats supplied for each product.

Product range

• Sizes: 1SVI, 10SVI, 15SVI (other sizes referenced in filters: 3SVI, 5SVI, 22SVI, SVI33, SVI46, SVI66, SVI92)
• Nominal power examples: 0.37 kW; 0.55 kW; 0.75 kW; 1.1 kW; 1.5 kW; 2.2 kW; 3 kW; 4 kW; 5.5 kW; 7.5 kW; 11 kW; 15 kW (up to ~30 kW in filters)

Example product codes

• 10SVI02-02CG007T5 — Version C; Size 10SVI; Nominal power 0.75 kW
• 10SVI03-03CG011T5 — Version C; Size 10SVI; Nominal power 1.1 kW
• 15SVI06-06CG055T5 — Version C; Size 15SVI; Nominal power 5.5 kW
• 1SVI08-08EG005T5 — Version E; Size 1SVI; Nominal power 0.55 kW
• 15SVI15-15CG150T5 — Version C; Size 15SVI; Nominal power 15 kW

Available versions / options

• Version C — with coupling and cartridge seal
• Version E — with extended shaft
• Version S — coupling version (listed in filters)

Document types available

• 2D (.dxf, .wmf)
• 3D (.stp)
• BIM (Revit .rfa, IFC .ifc)
• Interactive 2D and 3D previews

Technical specifications

• Series: e-SVI
• Common nominal powers: 0.37–15 kW (filter options up to ~30 kW)
• Available formats per product: 2D, 3D and BIM files
• Each product entry indicates version, size and available document types
