Roll-up industrial door

stainless steelsteel304 stainless steel

Overview
The Manusa high-speed roll-up steel door is designed for industrial areas with heavy vehicle, mobile machinery and pedestrian traffic. Suitable for warehouses, loading bays and industrial units, it provides compact installation, improved operator comfort and reduced draughts. The product is modular and configurable to customer requirements through a range of options.

Applications and benefits

• Suitable for warehouses, loading docks and industrial zones with intensive traffic.
• Compact design enabling installation in existing openings without excessive footprint.
• High wind resistance to limit draughts and maintain internal conditions.
• Configurable: motor positions, covers, windows and customized fabric available.

Standard equipment

• Standard push-button control from internal and external sides.
• Safety systems that detect obstacles and automatically raise the curtain.
• Manual override for raising in case of power failure.

Optional equipment

• Motor position: lateral or frontal; right or left configuration.
• 304 stainless steel structure (optional).
• Motor cover.
• Opening systems: UPS, remote control, radars, sensors.
• Control cabinet with frequency converter (inverter).
• Opening speed adjustable up to 2.0 m/s depending on dimensions.
• Colored or silk-screen printed custom fabric.

Colors

• RAL 9005
• RAL 8014
• RAL 7016
• RAL 7037
• RAL 7038
• RAL 5010
• RAL 5005
• RAL 5002
• RAL 6026
• RAL 3002
• RAL 2004
• RAL 1003
• RAL 1014
• RAL 9016

Peepholes

• Shapes: square and rectangular options.
• Positions: horizontal or vertical placement alternatives.
• Quantity: multiple peepholes can be specified.

Commercial notes and application guidance
Doors can be configured for indoor or outdoor use according to frequency of operation, opening dimensions and required wind resistance. Higher wind-resistance classes (eg. Class 3) are available within the range upon request.

Technical specifications

• Maximum dimensions: 4500 x 4500 mm
• Intended use: indoor and outdoor
• Wind resistance: Class 2 (higher classes available as options)
• Structure: lacquered steel in selectable RAL colour (304 stainless steel optional)
• Opening speed: standard 0.8 m/s (opening and closing); adjustable up to 2.0 m/s depending on dimensions
• Safety mechanisms: obstacle detection that raises the door; manual raising in case of power failure
• Standard drive: internal and external push-button operation; automation options available
