Basic data
Capacity -
20 x 1/1 GN
Number of meals per day -
150–300
Lengthwise loading -
1/1, 1/2, 2/3, 1/3, 2/8 GN
Width -
877 mm
Depth -
913 mm
Height -
1807 mm
Water inlet -
R 3/4"
Water outlet -
DN 50
Water pressure -
1,0 - 6,0 bar
Electric
Weight -
263 kg
Connected load -
37,2 kW
Fuse -
3 x 63 A
Mains connection -
3 NAC 400 V
"Hot air" output -
36 kW
"Steam" output -
36 kW
Gas
Weight -
284 kg
Height incl. flow guard -
-
Electrical connected load -
1,3 kW
Fuse -
1 x 16 A
Mains connection -
1 x 16 A
Gas supply/connection -
3/4" IG
Natural gas/liquefied petroleum gas LPG
Max. nominal heat input -
42 kW/42 kW
"Hot air" output -
42 kW/42 kW
"Steam" output -
38 kW/38 kW
Options
Left stop for appliance door -
-
Connection to energy optimisation system, potential-free contact -
Ethernet port -
-
Safety door lock -
Integrated fat drain (models 6-1/1, 10-1/1, 6-2/1, 10-2/1 only in conjunction with UG II or US IV) -
Externally attachable core temperature probe -
Lockable control panel -
Marine version (electric appliances only) -
Mobile with castors (4 castors with locking brake)
