Stone drainage channel CS1

paving

DESCRIPTION
Drain channel CS1 100×20 cm
Finish : sawn stone, old stone look

Sales unit

• Sales unit (U) = lm (linear metre)
• Equivalence: 1 lm = 1 drain channel

Geometric specifications (dimensions in cm)

• Length: 100
• Width: 20
• Thickness: 11.5 - 9.5
• Weight (kg / U): 52

Packaging

• Packaging (U / pallet): 24
• Disposable pallet: 110 × 90

MECHANICAL AND STANDARDS SPECIFICATIONS

• Splitting rupture (MPa): 5.2
• Water absorption: < 6 %
• Frost resistance: 0.758 kg/m²
• Slip resistance: medium (62)
• Standards: NF – EN – 1340

INSTALLATION

• Recommendations of standard NF P 98 335 and CCTG fascicle 29 apply.
• Install between +5°C and +30°C on sound substrate.
• Mortars are prepared or supplied as work progresses.
• The mortar bedding is levelled with a screed and placed progressively. Bedding thickness should be as uniform as possible (~4 cm).
• Slabs should be dampened, especially in hot weather.
• When laying, blend products from different batches to avoid visible differences.
• Joints are left between slabs. Joints must be filled with mortar not earlier than 24 h and not later than 72 h after laying.
• Minimum joint width: 5 mm.
• Immediately after jointing, clean the surface to prevent residue or film formation on the slabs.
• Provide expansion joints in accordance with regulatory requirements (10 lm or 20 m²).

MAINTENANCE

• The range is designed to reproduce natural or worked stone appearances; original colours are stable.
• Minimal maintenance required; natural patina develops over time.
• Applying a mineral stabiliser will facilitate cleaning and help preserve the original surface appearance.
• Do not use high-pressure cleaners or acidic products (risk of irreversible damage).
• Use de-icing salts sparingly and avoid prolonged residues.

COLOUR CHART
Colour chart available for sawn stone finish (appearance visuals and shade variations).

Characteristics / technical specifications

• Model: Caniveau CS1
• Dimensions (L×W×thickness): 100 cm × 20 cm × 11.5–9.5 cm
• Weight: 52 kg / unit
• Sales unit: lm (1 lm = 1 drain channel)
• Packaging: 24 U / pallet (disposable pallet 110×90)
• Splitting rupture: 5.2 MPa
• Water absorption: < 6 %
• Frost resistance: 0.758 kg/m²
• Slip resistance: medium (62)
• Standards: NF – EN – 1340
