Safety glass panel ECLAZ® SUN

solar controlacousticthermal insulating

Summary
ECLAZ® SUN is a double glazing solution with reinforced thermal insulation and solar control, designed to limit overheating while admitting natural light. It is suitable for highly exposed windows, large bay windows and conservatories. ECLAZ® SUN belongs to the ECLAZ® range and the "les engagés" line, which groups solutions focused on environment, health and comfort.

Operation and benefits
ECLAZ® SUN combines reinforced thermal insulation and solar control: in summer it reduces excessive heat to limit overheating periods and decrease air-conditioning use; in winter it provides effective insulation against the cold.

Applications
Designed for highly exposed windows, large bay windows and conservatories. Compatible with low-carbon substrates (e.g. ORAÉ).

Possible options

• Safety for protection of people and property: STADIP® PROTECT
• Acoustic performance to reduce external noise: STADIP® SILENCE
• Reduced maintenance of glazing: BIOCLEAN®

Advantages

• Optimal thermal comfort year-round
• Maintain view to the outside while reducing the need for summer shading
• Reduce use of air-conditioning in hot periods and heating in winter, enabling energy savings

Performance
ECLAZ® SUN enables significant energy savings (2023 study by the Passive House Institute): up to -10% heating in northern France and up to -23% in the south, compared with double glazing from before 2000. It reduces the overheating period by 56% (time above 26°C) without relying on air-conditioning or shading. It meets RE2020 requirements in southern France thanks to a good balance between thermal insulation, light transmission and solar factor.

Performance table (excerpt)
Glazing composition (Argon filled insulating glass mm) | Visible light transmission (TL %)| Solar factor (g %)| Thermal transmittance coefficient (Ug)| Acoustic Rw (C;Ctr) (dB)| Security class EN356
4 ECLAZ® SUN-16-4 | 72 | 38 | 1.0 | 30 | NA
4 ECLAZ® SUN-16-44.2 SILENCE | 71 | 38 | 1.0 | 39 | P2A
4 ECLAZ® SUN-16-44.2 PROTECT | 71 | 38 | 1.0 | 37 | P2A
4 ECLAZ® SUN-16-SP510 PROTECT | 71 | 38 | 1.0 | 38 | P5A

Note: TL = visible light transmission (higher value = brighter interior). g = solar factor (lower value = more solar heat filtered). Ug = thermal transmittance coefficient (lower value = better heat retention).

Characteristics / technical specifications

• Type: Double glazing with solar control coating
• Commercial name: ECLAZ® SUN
• Product family: ECLAZ® range, "les engagés" line
• Recommended applications: highly exposed windows, large bay windows, conservatories
• Compatibility: low-carbon substrate (e.g. ORAÉ)
• Energy savings (2023 study): up to -10% (Northern France) / -23% (Southern France) in heating vs older double glazing
• Overheating period reduction: ~56% (time >26°C)
• Compliance/performance: designed to meet RE2020 requirements (in Southern France depending on configuration)
• Examples of compositions and performance: see performance table above (TL, g, Ug, acoustics, security class)
