Safety glass panel ECLAZ® ZEN

solar controlinsulatingacoustic

Description
ECLAZ® ZEN succeeds ECLAZ® ONE. It is an insulating double glazing that balances solar gain and thermal protection: it blocks about half of solar heat in summer while ensuring improved thermal insulation in winter. Designed to reduce the use of artificial lighting, air conditioning and heating according to the season, ECLAZ® ZEN improves indoor comfort year-round. ECLAZ® ZEN belongs to the ECLAZ® coated-glass range and is also included in the “les engagés” line, which groups solutions focused on environment, health and well-being.

Applications
ECLAZ® ZEN is specifically designed for use in double or triple glazing and is suitable for all facades. It is compatible with the low-carbon substrate ORAÉ®. Optional treatments can be combined to enhance specific aspects of the glazing:

• Safety to protect people and property: STADIP® PROTECT
• Acoustic improvement to reduce external noise: STADIP® SILENCE
• Self-cleaning treatment to reduce maintenance: BIOCLEAN®

Advantages

• Thermal comfort: comfortable indoor temperatures in summer and winter.
• Natural light: high incoming daylight transmission.
• Energy savings: reduced use of air conditioning, heating and artificial lighting.

Performances
ECLAZ® ZEN reduces heating and cooling needs by 16% compared with a previous-generation double glazing (before 2000). It shortens the overheating period by 34%, reducing the hours above 26°C during hot months without requiring air conditioning or shading, compared with an older-generation double glazing without thermal control or LOW-E. ECLAZ® ZEN can meet RE2020 requirements thanks to the balance between its thermal insulation coefficient, light transmission and solar factor.

Performance table (example configurations, Argon gas insulating glass mm)
Composition | Visible light transmission (TL %) | Solar factor (g %) | Ug (W/m².K) | Acoustic Rw (C;Ctr) (dB) | Security class EN356
4 ECLAZ® ZEN-16-4 | 80 | 53 | 1.0 | 30 | NA
4 ECLAZ® ZEN-16-44.2 SILENCE | 79 | 52 | 1.0 | 39 | P2A
4 ECLAZ® ZEN-16-44.2 PROTECT | 79 | 52 | 1.0 | 37 | P2A
4 ECLAZ® ZEN-16-SP510 PROTECT | 78 | 53 | 1.0 | 38 | P5A

TL (visible light transmission): measures incoming light; the higher the value, the brighter the interior.
g (solar factor): measures transmitted solar heat; the lower the value, the greater the solar filtering (solar control).
Ug: thermal insulation coefficient; the lower the value, the better the thermal performance.

Characteristics / technical specifications

• Type: double glazing (adaptable to triple glazing)
• Technology: coated glass (ECLAZ®)
• Applications: windows, curtain walls, verandas, facades
• Substrate compatibility: ORAÉ® (low‑carbon substrate)
• Visible light transmission (examples): 78–80% depending on configuration
• Solar factor g (examples): 52–53% depending on configuration
• Thermal coefficient Ug: 1.0 W/m².K (examples indicated)
• Acoustic performance (examples): Rw ≈ 30 dB (standard), up to 39 dB with STADIP® SILENCE
• Security classes (examples): P2A or P5A depending on STADIP® PROTECT/SP510 configuration
• Energy impact: estimated 16% reduction in heating/cooling needs (Passive House Institute study, 2023, RE2020 simulation, west‑facing house, 16% glazing ratio relative to living area, without shutters)
