Urban lamp post FRIZA GEN2

contemporaryplasticcarbon

FRIZA GEN2 is a second-generation urban luminaire that pairs a timeless conical aesthetic with bio-sourced components and advanced LED and connectivity technologies to lower environmental impact while ensuring high visual comfort.

Applications

• Urban and residential streets
• Bridges
• Bike and pedestrian paths
• Railway stations and metros
• Car parks
• Squares and pedestrian areas

Key features and benefits

• Designed around circularity: protector and cover use bio-sourced / bio-circular materials to reduce carbon footprint (~28% reduction vs fossil-based plastic in specified parts).
• Connectivity-ready: supports Zhaga socket option and integration with smart-city systems such as Schréder EXEDRA for remote management.
• High visual comfort: internal diffuser with two protector options (clear or striated) to ensure low glare and optimized photometry.
• Robust and durable: IP66 ingress protection and IK10 impact resistance for demanding urban environments.
• Energy efficient: advanced LEDs delivering up to 150 lm/W and luminaire outputs from 1,300 to 6,900 lm.

Controls & connectivity

• Control protocols: DALI, 1-10V
• Control options: remote management, custom dimming profiles
• Socket option: Zhaga (ZD4i certified) — optional
• Associated control system: Schréder EXEDRA

Durability & materials

• Housing: Biopolymer (≈50% bio-sourced content)
• Protector: Polycarbonate with ~72% bio-circular content (ISCC PLUS)
• Optic: PMMA
• Designed for circularity and easy maintenance

Installation & maintenance

• Recommended mounting height: 3 m – 5 m
• Mounting: post-top slip-over Ø60 mm (delivered pre-wired; slip-over mounting with 2 screws)
• Canopy access for maintenance via 8 screws

Technical specifications

• Model: FRIZA GEN2
• Compliance: CE, ENEC, ENEC+, RoHS, Zhaga-D4i certified, UKCA
• Electrical class: Class I EU and Class II EU options
• Nominal voltage: 220-240 V – 50-60 Hz
• Surge protection: 10 kV
• Luminaire output flux: 1,300 lm – 6,900 lm
• Power consumption: 16 W – 52 W
• Luminaire efficacy (up to): 150 lm/W
• LED colour temperatures: Warm White 727, 730, 830; Neutral White 740
• Colour rendering index (CRI): 70 or 80
• Tightness level: IP66
• Impact resistance: IK10
• LED lifetime: 100,000 h – L95 (depending on configuration)
• Operating temperature range (Ta): -30°C to +55°C (with wind effect)
• Dimensions (AxBxC): 564 x 462 x 564 mm | 22.2 x 18.2 x 22.2 in
• Weight: 6.0 kg | 13.2 lbs
• Mounting possibilities: post-top slip-over – Ø60 mm
• Environmental benefit: protector and cover in bio-sourced materials; ~28% carbon footprint reduction vs traditional fossil-plastic alternatives (for specified parts)
