Mixer tap with soap dispenser EXTREME CS DP DUO

for washbasinwall-mountedelectronic

Product overview Touch-free electronic soap dispenser and touch-free wall-mounted electronic faucet supplied as a matching Soap & Water Duo. Activated by concealed sensors; chrome plated body with other finishes available. Includes a 1 liter soap bottle and bottle support. The set is designed to provide a complete germ-free and automated environment for commercial restrooms. Part Number: 237806.

Faucet features

• Extreme CS DP Touch-free wall-mounted electronic faucet.
• For cold or premixed water.
• For concealed installation in brick walls.
• IP67 dual power input box allows use with a 9V battery or 9V transformer.
• Can be powered by a 9V transformer with integrated backup using a 9V lithium battery to operate during power failure.
• Chrome plated body; other finishes available.
• Activated by concealed sensor built into the spout.
• Filter included.
• Sensor includes a low battery indicator.
• Adjustable settings by remote control: sensor range, security time, delay in, delay out, on-off and reset to factory settings.

Soap dispenser features

• Matching touch-free electronic Extreme CS DP soap dispenser for wall mounted installations.
• Activated by infrared sensor.
• Chrome plated body; other finishes available.
• Features a low battery indicator.
• Includes a 1 liter soap bottle and bottle support.
• Optional for remote installation: extension cable and longer piping.
• Remote control functions: soap quantity selection, refill the soap tank, temporary off, return to factory settings.

Application Touch-free electronic faucet and soap dispenser activate automatically when users place their hands in the sensor range and stop when hands are removed. The soap dispenser closes automatically without dripping. The Duo helps ensure hygiene and cleanliness in commercial restrooms and creates a complete germ-free automated environment.

Use Combines an elegant design with vandal-resistant features. Easy installation and long lasting performance even in harsh installation sites. Helps washrooms stay clean and saves water and soap. Prevents cross contamination. Ideal for offices, hotels, restaurants and all commercial restroom environments.

Caractéristiques / spécifications techniques

• Power source: 12V Transformer; 6×1.5V D Batteries; 9V Alkaline Battery; 9V Transformer.
• Water supply: Cold or premixed water (1 inlet).
• Installation: Deck Mounted.
• Activation: Concealed infrared sensor in spout (faucet) and infrared sensor (soap dispenser).
• Body finish: Chrome plated (other finishes available).
• Includes: 1 liter soap bottle and bottle support (soap dispenser); filter (faucet).
• Remote control adjustable functions: sensor range, security time, delay in/out, on/off, reset to factory settings; soap quantity selection, refill, temporary off (soap dispenser).
• Part Number: 237806.
