Door latch CPM / CPMV12

steelsatinhigh-gloss

Product series
Fittings and accessories series designed for glass doors and architectural glazing systems. Components in the T / TV12 family provide mechanical clamping and sealing for framed or frameless applications.

Available references / variations in the T / TV12 range

• S1LAA
• S1LAAS
• S1LAC
• S1LBBE
• S1LBC
• S1LBD
• S1LEE
• A1A2
• A1A2S
• ALP
• GBPC
• CGPV/TPV
• CPM / CPMV12
• CPMF
• PM / PMV12
• PMF
• PV6
• PV8
• PV10
• S1LT
• SLT
• SR
• TP1
• TP2
• TP3
• SL90ºT

General characteristics

• Glass clamping plates made from 4 mm thick stainless-steel sheet AISI 304
• Stainless steel screws A2
• Glass clamping seals made of cork rubber material
• Finishes: Polished stainless steel – Satin stainless steel

Recommended door dimensions

• Glass thickness 10 mm (T)
• Glass thickness 12 mm (T V12)
• Door size example: 1100 x 2500 mm
• Load: 70 kg per unit

OPTIONS AVAILABLE ON REQUEST

• Electrolytic finishes
• RAL colours
• VG pieces with special angles
• Special pieces manufactured according to specific needs

Technical specifications

• Material main components: AISI 304 stainless steel (4 mm plate for clamping plates)
• Fasteners: stainless steel A2 screws
• Seals: cork rubber glass clamping seals
• Typical finishes: polished or satin stainless steel; special finishes available on request
• Recommended glass thickness: 10 mm or 12 mm depending on reference (T / T V12)
• Recommended maximum load per unit: 70 kg (example door size 1100 x 2500 mm)
