Door latch PM / PMV12

steelsatinhigh-gloss

Product overview
Glass clamping fittings designed for glazing systems, framed doors and display cases. Series T / TV12 provides modular components for 10–12 mm glass in commercial and architectural applications.

Variants / references available

• S1LAA – Single-glass fixing without internal anchor
• S1LAAS – Single-glass fixing floor/ceiling
• S1LAC – Single-glass fixing
• S1LBBE – Single-glass fixing with anchoring holes on external fins
• S1LBC – Single-glass fixing
• S1LBD – Single-glass fixing at corners
• S1LEE – Single-glass fixing with anchoring holes on external fins
• A1A2 – 90° angle fixing
• A1A2S – 90° angle fixing floor/ceiling
• ALP – Lateral door support
• GBPC – Bottom guide for sliding door
• CGPV/TPV – Pivot point / showcase miter
• CPM / CPMV12 – Latch + strike plate (pressure)
• CPMF – Latch + strike plate (pressure)
• PM / PMV12 – Pressure latch
• PMF – Pressure latch
• PV6 – Showcase hinge for 6 mm glass
• PV8 – Showcase hinge for 8 mm glass
• PV10 – Showcase hinge for 10 mm glass
• S1LT – Roof glass fixing
• SLT – Two-glass roof fixing
• SR – Sign support
• TP1 – Single pressure stop
• TP2 – Double pressure stop
• TP3 – Carpentry stop
• SL90ºT – 90° roof glass fastening

General characteristics

• Glass clamping plates in 4 mm AISI 304 stainless-steel sheet
• Stainless steel screws A2
• Glass clamping seals in cork-rubber material
• Available finishes: Polished stainless steel, Satin stainless steel

Recommended door dimensions

• Compatible glass thicknesses: 10 mm (T), 12 mm (TV12)
• Recommended door size: up to 1100 x 2500 mm
• Recommended load capacity: 70 kg per unit

Options available on request

• Electrolytic finishes
• RAL colours
• VG parts with special angles
• Custom parts according to project needs

Characteristics / technical specifications

• Series: T / TV12
• Model: PM / PMV12
• Main material: Stainless steel AISI 304 (4 mm plate)
• Screws: Stainless steel A2
• Seals: Cork-rubber material
• Available finishes: Polished stainless steel, Satin stainless steel (electrolytic and RAL on request)
• Compatible glass thicknesses: 10 mm (T), 12 mm (TV12)
• Recommended door dimensions: up to 1100 x 2500 mm
• Recommended load capacity: 70 kg per unit
• Applications: Glazed doors, display cases and glass assembly systems for commercial and architectural projects
