Entry door SMARTIA M15000 BR

aluminiumswingcontemporary

Description SMARTIA M15000 BR is a burglar-resistant hinged system designed for the construction of high-security entrance doors and security enclosures. It is engineered for applications requiring enhanced anti-burglary protection, such as banks, public buildings and secure facilities.

Advantages

• Cost-effective solution for security doors
• Enhanced level of burglar resistance (RC2)
• Contemporary, flat exterior appearance
• Simple operation with high functionality
• Certified product performance

Certificates

• Aluminium TUV Austria OK Recycled (product certification)

Generic THERMAL INSULATION: No
EXTERIOR SHAPE: Flat

Technical Characteristics FRAME DEPTH: 50 mm
MINIMUM VISIBLE ALUMINIUM FACE WIDTH AT THE CENTRAL VERTICAL COLUMN (ADJOINING PROFILE): 39 mm
GLAZING TYPE: Single - Double
MAXIMUM GLAZING THICKNESS: 5 up to 40 mm
MECHANISM: Door locking mechanism
SEALING METHOD: 2 levels of watertightness with EPDM gaskets
MINIMUM THRESHOLD HEIGHT: 18.5 mm

Performance BURGLAR RESISTANCE: RC2

Characteristics MINIMUM VISIBLE ALUMINIUM FACE HEIGHT: 121.4 mm
SASH DEPTH: 50 mm
SASH WEIGHT: up to 180 Kg
TYPES OF TYPOLOGY: For all entrance door typologies with glass or aluminium panels

Typologies

• Hinged door inwards/outwards
• Double leaf door inwards/outwards opening
• Hinged door inwards/outwards with insulation panel & fixed pane
• Hinged door inwards/outwards with insulation panel, fixed pane & fanlight

Characteristics / Technical specifications

• Model: SMARTIA M15000 BR
• Brand: Alumil
• Thermal insulation: Non-insulated
• Frame depth: 50 mm
• Sash depth: 50 mm
• Minimum visible aluminium face width (central column): 39 mm
• Minimum visible aluminium face height: 121.4 mm
• Glazing supported: 5 up to 40 mm
• Glazing type: Single or double
• Mechanism: Door locking mechanism
• Sealing: 2 levels of watertightness with EPDM gaskets
• Minimum threshold height: 18.5 mm
• Burglar resistance: RC2
• Sash maximum weight: up to 180 Kg
