Wall-mounted pergola ST-100-KS-KD

self-supportingaluminumwith mobile slats

Short description
A reinforced outdoor kitchen steel pergola designed for wider grill islands, patio kitchens and custom cooking zones. The ST-100-KS-KD features a 100 x 100 mm aluminum middle post, 150 x 96 mm aluminum middle beam, 180 x 34.5 mm louver roof, 60 kg/m²+ load capacity and 3 x 5 m / 3 x 6 m size options.

Product overview
The ST-100-KS-KD is built for outdoor kitchen and wider backyard cooking layouts. Its aluminum middle post and 150 x 96 mm aluminum middle beam provide structured support for larger 3 x 5 m and 3 x 6 m spans, accommodating grill islands, serving counters and bespoke kitchen zones. The model includes reinforced middle-beam support, adjustable louver roof rotation and optional LED lighting.

Built for wider cooking layouts

• Scene: Outdoor kitchens, grill islands, patio bars and backyard cooking programs
• Support: Middle aluminum post and beam support for wider layouts
• Package: LED lighting and side-option accessories to create a complete kitchen pergola offer

Technical data (summary)
Category: Outdoor Kitchen Pergola
Support: Aluminum Middle Beam
Standard sizes: 3 x 5 m / 3 x 6 m
Load capacity: 60 kg/m²+

Selling points

• Reinforced middle beam (aluminum 150 x 96 mm) for stronger support of wider kitchen spans
• Designed for wider cooking zones: 3 x 5 m and 3 x 6 m formats
• Strong louver roof (180 x 34.5 mm) for substantial shade and ventilation control
• Load capacity 60 kg/m²+ supports confident project discussions
• LED options (warm white / white / RGB) for evening cooking and hosting

Configuration and package options

• Grill island coverage and wider prep counter support
• Middle support structure: aluminum middle post (100 x 100 mm) and aluminum middle beam (150 x 96 mm)
• Two standard sizes: 3 x 5 x 2.4 m and 3 x 6 x 2.4 m
• LED strips available: warm white, white or RGB
• Side comfort options: zip blinds (manual or motorized), sliding shutters, adjustable louver walls, fixed slat walls, glass sliding doors, folding glass doors

Installation directions

• Wall-adjacent kitchen: placed beside a house wall, service counter or restaurant-side kitchen zone
• Freestanding kitchen pavilion: four-post placement supporting grill islands and backyard entertaining zones

Colors & add-ons

• Standard color swatches: Light Neutral, Graphite Grey, Dark Charcoal
• Accessories: LED louver lighting, Zip blind side screens, Sliding shutter, Adjustable louver wall, Fixed slat wall, Glass sliding door, Folding glass door

Notes
The product is positioned specifically as an outdoor kitchen pergola with reinforced middle-beam support for wider grill islands, patio kitchens and custom cooking zones. Roof rotation up to 120° (adjustable louvers) and a strong louver roof profile enhance shade and ventilation control.

Specifications / technical characteristics

• Model: ST-100-KS-KD
• Category: Outdoor Kitchen Pergola
• Post: 100 x 100 mm
• Middle post: Aluminum 100 x 100 mm
• Side beam: 150 x 35 mm
• Middle beam: Aluminum 150 x 96 mm
• Water gutter: 32 x 56 mm
• Louver roof: 180 x 34.5 mm
• Available sizes: 3 x 5 x 2.4 m / 3 x 6 x 2.4 m
• Standard sizes offered: 3 x 5 m and 3 x 6 m
• Load capacity: 60 kg/m² +
• LED strips: Warm white / White / RGB options
• Roof rotation: up to 120° (adjustable louvers)
• Product position: Outdoor kitchen / wider custom cooking zone
