Air conditioning control module CSTFR1

DIN railIPanalog

Function: Programmable Controller, Supply voltage [V] AC: 110 - 230, Communication type: CANBUS; RS485; MODBUS, Packing format: Industrial pack, Quantity per packing format: 24 Gross weight - 0.352 Kg Net weight - 0.246 Kg Volume - 2.326 Liter Analog inputs (AI) [pc] - 16 pc Analog outputs (AO) [pc] - 6 pc Approval - CE GOST R Buzzer - Yes Communication type - CANBUS MODBUS Connector kit Code No. - 080G0185 Connector kit included - No Digital inputs (DI) [pc] - 22 pc Digital outputs (DO) [pc] - 20 pc Enclosure rating IP - IP40 Frequency [Hz] - 50/60 Hz Function - Programmable controller Packing format - Industrial pack Power consumption [W] - 6 W Product accessories - Electron. control accessories Product group - Programmable controllers Product Name Description - Program. controller, 6 relays Quantity per packing format - 24 pc REACH Candidate List substances - No Real time clock - No Serviceable - No Supply voltage [V] AC [max] - 230 V Supply voltage [V] AC [min] - 110 V Type designation - CSTFR14000070
