Function: Programmable Controller, Supply voltage [V] AC: 24, Communication type: CANBUS; RS485; MODBUS, Packing format: Multi pack, Quantity per packing format: 12
Gross weight - 0.57 Kg
Net weight - 0.56 Kg
Volume - 2.799 Liter
EAN - 5702428910811
Analog inputs (AI) [pc] - 8 pc
Analog outputs (AO) [pc] - 4 pc
Approval - CE
EAC
LLC CDC TYSK
UL
Buzzer - Yes
Communication type - CANBUS
MODBUS
RS485
Connector kit Code No. - 080G0180
Connector kit included - Yes
Digital inputs (DI) [pc] - 8 pc
Digital outputs (DO) [pc] - 8 pc
Enclosure rating IP - IP40
Frequency [Hz] - 50/60 Hz
Function - Programmable controller
Identical product - 080G0303
Mounting method - DIN rail
Packing format - Multi pack
Power consumption [W] - 10 W
Product accessories - Electron. control accessories
Product group - Programmable controllers
Product Name Description - Program. controller, 8 relays
Quantity per packing format - 12 pc
REACH Candidate List substances - No
Real time clock - Yes
Serviceable - No
Supply voltage [V] AC - 24 V
Supply voltage [V] DC - 24 V
Supply voltage [V] DC - 24 V
Type - MCX08M2
Type designation - MCX08M2
