Crawler bulldozer TD-15R EXTRA WT

crawler bulldozer
crawler bulldozer
crawler bulldozer
crawler bulldozer
crawler bulldozer
crawler bulldozer
crawler bulldozer
Add to favorites
Compare this product


Characteristics

Locomotion
crawler
Engine power

154 kW
(209.38 hp)

Description

The TD-15 medium crawler dozer Series are available in several versions starting from 190hp with an operating weight of 21.3t. These powerful dozers blend brute force with predicable and precise control and are engineered for optimum performance in road construction, land clearing and on construction sites. Customers can specify their machines in either Standard (STD), Wide Track (WT) Long Track (LT) or Low Ground Pressure (LGP) versions. The machines can also be engineered for superior performance in Landfill Applications (LA). KEY SPECIFICATIONS Driveline Engine Manufacturer / Model / TierCummins/QSB 6.7/T4F Displacement 6.70 l Rated Speed 2000 RPM Engine Output - Net 154 kW Rated Speed - Torque 1500 RPM Engine Torque 949 Nm Transmission Type - Fwd Rev Speeds Powershift - 6/6 Carrier Rollers / Track Rollers 2/8 Shoe Pitch 203 mm Track Shoe Width 762 mm Ground Contact Area 46000 cm2 Number of Shoes 43 Capacities Fuel Tank 330 l Hydraulic Tank 60 l Blade Capacity 5.95 m3 Dimensions Height Top of ROPS (Max)3450 mm Ground Clearance 445 mm Width - Over Tracks 2790 mm Track Length - On Ground 3050 mm Blade Width 3300 mm Ground Clearance 445 mm Performance Speed Forward - Maximum10.50 km/h Speed Reverse - Maximum12.30 km/h Ground Bearing Pressure45.70 kPa Drawbar Pull Maximum580 kN Implement Pump Flow164.00 l/min
