Urban lamp post STANZA
gardentraditionalpolycarbonate

Urban lamp post - STANZA - ECLATEC International - garden / traditional / polycarbonate
Urban lamp post - STANZA - ECLATEC International - garden / traditional / polycarbonate
Urban lamp post - STANZA - ECLATEC International - garden / traditional / polycarbonate - image - 2
Urban lamp post - STANZA - ECLATEC International - garden / traditional / polycarbonate - image - 3
Urban lamp post - STANZA - ECLATEC International - garden / traditional / polycarbonate - image - 4
Urban lamp post - STANZA - ECLATEC International - garden / traditional / polycarbonate - image - 5
Urban lamp post - STANZA - ECLATEC International - garden / traditional / polycarbonate - image - 6
Add to favorites
Compare this product

Characteristics

Type
urban, garden
Style
traditional
Material
polycarbonate
Light source
LED
Number of lights
single, double
Shape
lantern, candelabra, square
Support type
without lighting pole
Protection class
IP66
Color
gray, customizable color
Other characteristics
smart, IK10, with presence detector
Height

745 mm, 760 mm
(29.33 in, 29.92 in)

Length

540 mm
(21 in)

Width

540 mm
(21 in)

Color temperature

2,200 K, 2,400 K, 2,700 K, 3,000 K, 4,000 K

Luminous flux

11,735 lm

Power

102 W

Description

HOUSING: Die-cast aluminium body. Arms in polycarbonate (UV treatment) BOWL: Thermally toughened flat glass FINISH: Polyester powder coating, any colour available SOURCES: SOMLED 1 / BLS Strips COLOUR TEMPERATURE: SOMLED 1: 3000K or 4000K
 BLS: Amber*, 2200 K, 2400 K, 2700 K, 3000K, 4000 K OPTICAL: ORALENS / QUADRALENS FLUX & POWER**: Up to 11 735lm; 102W

 ELECTRICAL CLASS: Class I or II WIRING: Pre-wired at the factory (6 m) (post top version only) MOUNTING: Post top, suspended *Approx. 1800K **At 3000K, in accordance with performance standards IEC 62717 and IEC 62722 (+/-5% tolerance)
