Recessed downlight GIMBAL

LEDroundoval

Product overview
The cardanic suspension of the Gimbal recessed spotlight creates a precise, easy-to-adjust swivel mechanism. Its compact design keeps the luminaire head centre stable during aiming, making it particularly suitable for architectural lighting from ceiling channels and coves. The special mounting bracket allows installation in on-site ceiling channels. Multiple sizes, wattages and light distributions enable flexible lighting concepts for retail, hospitality and projects requiring discreet, targeted accent or ambient lighting.

Key features

• Oval flood freely rotatable: The Spherolit oval flood lens rotates 360° on round luminaire heads to adapt the beam shape to various objects.
• Cardanic suspension: Facilitates precise aiming, especially effective with high ceilings where small swivel movements significantly change beam position.
• Suitable for ceiling channels: Compact geometry and central pivot point make selected versions ideal for installation in ceiling channels.
• Shallow recess depth: Versions designed for limited installation depth while maintaining quality of light.

Customization / Variants

• Connection: 3‑ or 5‑pole plug with connection cable (Wago or Wieland).
• Housing: standard black; additional colours available on request (up to 10,000 options).

Product details

• 1. Spherolit lens

  • Light distributions: narrow spot, spot, flood, wide flood, extra wide flood, oval flood, wallwash.
  • Oval flood: 360° rotation.
• 2. LED module

  • High‑power LEDs: warm white (2700K or 3000K) or neutral white (3500K or 4000K).
  • Collimating lens: optical polymer.
• 3. Luminaire

  • Colour: Black (standard); other colours on request.
  • Material: Cast aluminium, powder‑coated.
  • Gimbal suspension: polymer.
  • Tilt/swivel: 0°–40°; up to 60° in the channel longitudinal direction.
  • Mounting bracket: steel, powder‑coated.
• 4. Control gear

  • Options: switchable, phase dimmable, DALI dimmable, Casambi Bluetooth.
  • Phase dimmable: compatible with external trailing‑edge dimmers.

Applications
Accent and ambient lighting in retail, hotels, restaurants and architectural projects where discreet, effective lighting is required from ceiling channels or coves.

Technical specifications

• Light source power range (recessed spotlights): 2 W – 37.4 W.
• Luminous flux range (recessed spotlights): approx. 194 lm – 4427 lm.
• Available light distributions: narrow spot, spot, flood, wide flood, extra wide flood, oval flood, wallwash.
• Oval flood: 360° rotation.
• LED colour temperatures: 2700K, 3000K, 3500K, 4000K.
• Collimating lens: optical polymer (Spherolit).
• Housing: cast aluminium, powder‑coated; standard black, other colours on request.
• Gimbal suspension material: polymer.
• Mounting bracket material: steel, powder‑coated.
• Tilt / swivel: pivotable 0°–40°; up to 60° along channel.
• Control options: switchable, phase dimmable (trailing edge), DALI, Casambi Bluetooth.
• Designed for installation in ceiling channels; versions for shallow recess depths available.
