Rectangular shower base S-LINE

tileablefloor levelconcrete

Easy Drain shower Board S-line is suitable for both new installation and renovation projects. Each side of the shower board can be shortened up to 80 cm and is coated with special plastic mortar mix, that can be tiled immediately, to ensure a 100% watertight installation. Easy Drain S-line Shower Board is supplied as a complete set including; S-line shower drain (reversible grate), trap body, sloped shower board and sealing set. DRAINAGE CAPACITY according to EN 1253 GRATE Height adjustable grate SIPHON Easy to clean CUSTOM LENGTH Can be shortened on site SLOPE Easy slope creation without mortar or cement Shower Drain model Rectangular shower drain Application New construction, Renovation Certification DIN 18534, EN1253, ETAG-022 Substrate Concrete / Sand Cement, Lewis sheets, Wooden floors Floor finish Cast / screed, Glass Mosaic, Natural stone, Thin tiles, Tiles / Mosaic Installation depth (mm) 104 Connection (⌀) 50 (Global) / 56 (UK) Height adjustable feet included No Outlet type Rotatable outlet Outlet Horizontal (Vertical outlet optional) Location in shower One-sided, Three-fold Max. drainage capacity wall (l/min) 41 MaxDrainageCapShowerDrain 41 Pre-assembled sealing membrane (WPS) Yes Siphon characteristics Cleanable, Height adjustable, Pivotable & adjustable Grate Brushed stainless steel / Tile Grate pattern Zero / Closed TAF frame type TAF (Tile Adjustable Frame) Frame material Stainless steel (304) Extension set available No
