Rectangular shower base AQUA

above floorconcretenon-slip

WATER PROTECTION SYSTEM 10-year warranty DRAINAGE CAPACITY according to EN 1253 CONNECTION 360° rotatable SIPHON Removable and easy to clean OUTLET Horizontal outlet CUSTOM LENGTH Can be shortened on site TRAP BODY Pivoted and height adjustable MEMBRANE 100% Watertight SHOWER DRAIN MODEL Rectangular shower drain SERIE Shower boards APPLICATION New construction, Renovation CERTIFICATION DIN 18534, EN1253, ETAG-022 SUBSTRATE Concrete / Sand Cement, Lewis sheets, Wooden floors MAX. DRAINAGE CAPACITY ENTRANCE (L/MIN) 41 INSTALLATION DEPTH (MM) 119 CONNECTION (⌀) 40 HEIGHT ADJUSTABLE FEET INCLUDED No OUTLET TYPE Rotatable outlet WATER SEAL (MM) 28 / 50 INSTALLATION OPTION Floor OUTLET Horizontal (Vertical outlet optional) LOCATION IN SHOWER Free in the floor MAX. DRAINAGE CAPACITY WALL (L/MIN) 30 MAXDRAINAGECAPSHOWERDRAIN 41 PRE-ASSEMBLED SEALING MEMBRANE (WPS) Yes SIPHON CHARACTERISTICS Cleanable, Height adjustable, Pivotable & adjustable GRATE Brushed stainless steel
