Installation
Two securing holes for ceiling installation. IP 20.
Some models can be covered with insulation. For further details please refer to the assembly instructions on our website.
Connection
Snap-in terminal block 5 x 2.5 mm², 1-phase through-wiring possible. Cable entry from top of the luminaire.
Design
Diffuser in specular opal acrylic. The Ø 550 mm version is equipped with a performance ring consisting of high-power LEDs and acrylic lenses.
Dimming
DALI/Phase-pulse control as standard. Eira Ø 550 requires two addresses for DALI.
LED-information
3000/4000 K CRI min. 90, MacAdam 3 SDCM.
Driver life-time: up to 50.000 h/10 % (max failure).
