Hanging light fixture INDUCON

surface mountedfluorescentlinear

Installation Surface mounted, wire catenary, tube or assembly rail. Connection Two cable entries fitted with blanking grommets Ø 23 mm – one at each end. 3-phase through-wiring 5x2.5 mm². Snap-in terminal block 5x2.5 mm² at each end. Design Luminaire body and end-caps of alu-zinc. Louvre Square lamell – louvre of anodised aluminium. Lamell – lamell basic louvre of white enamelled sheet steel (RAL 9016). The louvre remains attached when opened. The luminaire can be supplemented with a louvre at a later date. Reflector Medium beam reflector of satin matt metallised aluminium with excellent reflection characteristics (> 92 %). Accessories When supplemented with the cover plate IP 23 enclosure class is obtained, see Accessories. Miscellaneous PVC-free internal wiring. When supplemented with the cover plate IP 23 the luminaire satisfies the requirements for D-marking, i.e. limited surface temperature (90 °C).
