Access control control panel BRAIN 17
wall-mountedcommercial

access control control panel
access control control panel
Add to favorites
Compare this product


Characteristics

Use
for access control
Installation
wall-mounted
Options
commercial

Description

Power supply (Vac) 230 (+6% -10%) – 50Hz Absorbed power (W) 4 in Stand by Max. motor load (W) 800 Accessories max. load (mA) 500 Electric lock max. load (VA) 15 Operating ambient temperature (°C) -20 +55 Protection fuses 2 Function logics Automatic/Semi-automatic/Safety/Semi-automatic B/ Dead man C/Semi-automatic “Step by step”/ Automatic “Step by step” Opening / closing time Programmable (from 0 to 120 sec.) Pause time from 0 to 9,5 min. Closing leaf delay from 0 to 1,3 min. Opening leaf delay 2 sec. (can be excluded by display) Thrust force Adjustable via display on 50 levels for each motor Terminal board inputs Open/Open free leaf/Stop/Limit switch/USB Opening and closing safety devices/Power supply + earth/BUS G-WAY Terminal board outputs Flashing lamp/Motors/ 24 Vdc Accessories Power Supply/Failsafe/12Vac Electric Lock Power Supply/ Signalling lamp 24Vdc Quick-fit connector 3PIN each RQFZ Genius receiving Module/Integrated decodification Selectable functions Logics and pause time/Thrust force/ Opening and closing leaf delay/Reversing thrust/ Failsafe/Closing safety device logic/Pre-flashing/ Use of Limit Switches/Use of Encoder PROcoder Programming keys Simple or Complete work times learning, with or without limit switches or encoder, with or without slow-downs and radio code programming USB Input Firmware Update/Upload and Download installation configuration/Upload and Download radio codes
