DIN rail dimmer KA/D 0103.1for home automation systemsKNX
Add to favorites
Compare this product
Characteristics
- Assembly
- DIN rail
- Other characteristics
- for home automation systems, KNX
Description
Switching
Relative dimming
Absolute dimming
Status report, error report
Up to 15 scenes setting
Preset and set preset function
Staircase lighting function
Support set Brightness value after bus voltage recovery
Trailing edge phase dimming
Bus voltage 21-30V DC, Via KNX/EIB
Bus current <12mA
Bus consumption <360mW
Input voltage 230V AC (50/60Hz)
Max.output capacity (Dimming Actuator, 1/2-Fold) 500W per channel
Max.output capacity (Dimming Actuator, 4fold) 400W per channel
Output protection short-circuit and over temperat
