Electric radiator ECOREVIVA HYBRID

hot water501 w...750 w0...500 w

Product name
EcoReviva Hybrid - Hybrid replacement radiator

Overview
The energy-saving replacement radiator designed to replace old radiators while maintaining original dimensions. Suitable for heating and cooling; provides high efficiency at low supply water temperatures and helps reduce energy consumption.

Key features

• Only for DIN hub spacing
• For supply water temperatures of 35 °C and above
• Maintains original radiator dimensions while enabling lower supply temperatures and reduced energy costs
• Aluminium-copper heat exchanger & DBH (Dynamic Boost Hybrid) technology for improved efficiency and performance
• Optimises COP when used with heat pumps
• High efficiency with condensing boilers
• Suitable for heating and cooling applications
• Breeze function: fan-driven airflow that does not require cold water
• Functions: Heating, Cooling, Breeze
• Made in Belgium (factory origin)
• 30 years warranty (product feature)

Outputs / Performance table
Productcode | Height [CM] | Length [CM] | Type | Position [Fan Speed] | Cooling non condensing (16/18/27°C) [Watts] | Heating (35/30/20°C) [Watts] | Heating (45/40/20°C) [Watts] | Heating (50/45/20°C) [Watts] | Heating (55/45/20°C) [Watts] | Sound pressure [dB(A)] | Electric power consumption [Watts] | Ordercode
1 | 40 | 55 | 11 | 1 | 191 | 246 | 474 | 592 | 647 | 26,0 | 48,0 | ECRW 040 055 11 XXX D09 BT1 32
2 | 40 | 55 | 11 | 2 | 205 | 263 | 508 | 634 | 693 | 30,0 | 54,0 | ECRW 040 055 11 XXX D09 BT1 32
3 | 40 | 55 | 11 | 3 | 242 | 311 | 601 | 750 | 820 | 40,0 | 68,0 | ECRW 040 055 11 XXX D09 BT1 32
4 | 40 | 55 | 16 | 1 | 214 | 301 | 581 | 726 | 793 | 26,0 | 48,0 | ECRW 040 055 16 XXX D09 BT1 32
5 | 40 | 55 | 16 | 2 | 230 | 323 | 624 | 779 | 851 | 30,0 | 55,0 | ECRW 040 055 16 XXX D09 BT1 32
6 | 40 | 55 | 16 | 3 | 305 | 428 | 826 | 1031 | 1126 | 41,0 | 72,0 | ECRW 040 055 16 XXX D09 BT1 32
7 | 40 | 55 | 21 | 1 | 234 | 416 | 779 | 963 | 1048 | 26,0 | 48,0 | ECRW 040 055 21 XXX D09 BT1 32
8 | 40 | 55 | 21 | 2 | 251 | 447 | 836 | 1034 | 1125 | 30,0 | 55,0 | ECRW 040 055 21 XXX D09 BT1 32
9 | 40 | 55 | 21 | 3 | 332 | 591 | 1106 | 1368 | 1488 | 41,0 | 72,0 | ECRW 040 055 21 XXX D09 BT1 32
10 | 40 | 65 | 11 | 1 | 234 | 301 | 580 | 724 | 791 | 26,0 | 55,0 | ECRW 040 065 11 XXX D09 BT1 32

Gallery notes
Before/after gallery images illustrate the replacement concept and visual comparison between original radiators and the EcoReviva Hybrid.

Specifications

• Model family: EcoReviva Hybrid (replacement radiator)
• Heat exchanger: aluminium-copper
• Integrated DBH (Dynamic Boost Hybrid) technology for boosted efficiency
• Operates efficiently with supply water temperatures ≥ 35 °C
• Compatible with heat pumps (maximises COP)
• Also efficient with condensing boilers
• Breeze function: fan-driven airflow independent of cold water supply
• Applications: heating, cooling and breeze mode
• Height and length variants as per performance table (e.g. 40x55 cm, 40x65 cm)
• Fan speed / positions: 1 / 2 / 3 (configuration dependent)
• Acoustic: sound pressure values provided per configuration (dB(A) in table)
• Electric power consumption specified per configuration (Watts in table)
• Manufactured in Belgium
• Standard and extended colour/finish options available (standard colours; metallic and soft-touch finishes)
• 30 years warranty indicated
