Thermal insulation LINITHERM PAL N+F
polyurethane foamrigid panelfoam

Thermal insulation - LINITHERM PAL N+F - Linzmeier Bauelemente GmbH - polyurethane foam / rigid panel / foam
Thermal insulation - LINITHERM PAL N+F - Linzmeier Bauelemente GmbH - polyurethane foam / rigid panel / foam
Thermal insulation - LINITHERM PAL N+F - Linzmeier Bauelemente GmbH - polyurethane foam / rigid panel / foam - image - 2
Thermal insulation - LINITHERM PAL N+F - Linzmeier Bauelemente GmbH - polyurethane foam / rigid panel / foam - image - 3
Thermal insulation - LINITHERM PAL N+F - Linzmeier Bauelemente GmbH - polyurethane foam / rigid panel / foam - image - 4
Thermal insulation - LINITHERM PAL N+F - Linzmeier Bauelemente GmbH - polyurethane foam / rigid panel / foam - image - 5
Thermal insulation - LINITHERM PAL N+F - Linzmeier Bauelemente GmbH - polyurethane foam / rigid panel / foam - image - 6
Thermal insulation - LINITHERM PAL N+F - Linzmeier Bauelemente GmbH - polyurethane foam / rigid panel / foam - image - 7
Thermal insulation - LINITHERM PAL N+F - Linzmeier Bauelemente GmbH - polyurethane foam / rigid panel / foam - image - 8
Thermal insulation - LINITHERM PAL N+F - Linzmeier Bauelemente GmbH - polyurethane foam / rigid panel / foam - image - 9
Thermal insulation - LINITHERM PAL N+F - Linzmeier Bauelemente GmbH - polyurethane foam / rigid panel / foam - image - 10
Thermal insulation - LINITHERM PAL N+F - Linzmeier Bauelemente GmbH - polyurethane foam / rigid panel / foam - image - 11
Add to favorites
Compare this product

Characteristics

Type
thermal
Material
polyurethane foam
Format
rigid panel, foam
Location
exterior
Use
for roof, roof
Technical characteristics
high-performance, waterproof
Fire Class
EN 13501-1, DIN 4102-1
Options
with vapor barrier
Thermal conductivity

0.022 W/(m.K), 0.023 W/(m.K)

Length

242 cm
(95 in)

Width

100 cm
(39 in)

Thickness

Max.: 24 cm
(9.45 in)

Min.: 8 cm
(3.15 in)

Description

Over-rafter insulation system for efficient installation with minimum waste, even with irregular roof landscapes The reliable insulation ... For roof pitches from 20° Protection from electrosmog ... in perfect professional quality ... With integral vapour barrier With specially shaped edge joints Two-way use Cut-offs that occur when insulating covings and dormers are simply turned over and fitted on the opposite side finished. That saves material and time. With anti-glare surface With printed grid for fast installation Thermal insulation plus diffusion membrane Full-surface, seamless insulation Installed directly on rafters or boarding Suitable as temporary roof covering in combination with LINITHERM nail sealing tape ... for PUR(E) energy saving Protection from heat in summer Thermal protection in winter Insulating core made of PUR/PIR rigid foam Consistently high insulation value of TCL 023 Maximum insulation with minimum panel thickness Positive building biology: PUR/PIR rigid foam is free of CFC, HCFC, formaldehyde, and fibres Positive life-cycle assessment
