LED strip light MILUM

IP20IP44opal

Product overview
The MILUM Lightline is a miniaturized, compact lighting system offering a pleasant diffuse lighting effect. It is available as single luminaires and as a continuous lightline system. The configurator allows planning continuous lightlines down to the millimetre. The system is suitable for general lighting in private and commercial sectors and is offered in surface-mounted and pendant mounting variants.

Design & variants

• Available as direct-beam and omnidirectional modules with integrated through-wiring.
• The omnidirectional diffuse module is also offered as a single luminaire without feed-through wiring and with a height-reduced mounting rail.
• Modular lengths and variants cover single luminaires and light system / lightline configurations (examples shown in the range: 600–1800 mm).
• Selectable colour variations for lamp housing: natural anodised, black RAL 9005, white RAL 9003.

Lighting effect & comfort
The Lightline offers perfectly homogeneous, soft light without shadowing. It is designed for optimum visual comfort for general lighting tasks (kitchen, corridor, stairwell) and can be used as single luminaires (including IP44 versions for wet rooms) or as continuous rows for signalling in commercial properties.

Technical highlights

• High colour rendering: CRI >90
• Available correlated colour temperatures: 2700 K, 3000 K or 4000 K
• UGR ≤ 25 for good glare control (specified for several variants)
• Options with IP44 for bathroom/wet-room suitability (some mounted single-luminaire variants)
• Tool-less installation options for mounting rails in many configurator variants (mounting rails ordered separately when required)

MILUM in shop / configurator
MILUM is offered through a configurator enabling customized selection of single luminaires, pendant or mounted variants, and continuous lightline systems across the available modules and lengths.

Technical specifications

• Mounting: ceiling or wall for certain single luminaires; for pendant and many lightline variants: ceiling-mounted or pendant; tool-less installation on mounting rails available for configurator variants (mounting rails and some control gear to be ordered separately).
• Lamp housing: extruded aluminium (available natural anodised, black RAL 9005, white RAL 9003).
• Optics: opal acrylic glass diffuser; UGR ≤ 25.
• Lamps: integrated LED, CRI >90; available in 2700 K, 3000 K or 4000 K (variant-dependent).
• Service life: 50'7000h L90 B10 (Ta 25° C) (as specified on product pages).
• Control gear: PS 230 V / 50 Hz (specified for multiple variants).
• Lamp protection class: I or III depending on variant (variant-specific information provided on product pages).
• Protection level: IP 44 for certain single mounted luminaires (bathroom/wet-room suitable) and IP 20 for other variants; some single-luminaire I-shape variants have specific protection notes.
• Energy efficiency class: E.
• Available module/length examples in range: 600–1800 mm (single luminaires and lightline modules).
• Design & manufacture: RIBAG Design Studio; miniaturized system for flexible, high-quality residential and commercial lighting concepts.
