Recessed ceiling light fixture DIZCO

recessed wallhangingsurface mounted

Overview
The reduced, clear design language and advanced lighting technology of the pendant, ceiling and wall luminaires combine with the visual effect of a luminous glass pane. Light is reflected by an organically optimised printed dot grid on the glass, making the light visible and creating the perception of a floating luminous disc. DIZCO is a distinctive light source suitable for high‑end residential and commercial interiors.

Design
Design: RIBAG Design Studio

• Minimal, clear aesthetic based on a luminous glass pane
• High‑quality EGS safety glass combined with aluminium components
• Organically placed dot grid inspired by compound eyes to visualise light

Dot grid
An organically optimised dot grid is printed on high‑quality EGS safety glass. Approximately 60,000 dots are printed, increasing in size from centre to edge to visualise the light and create the perception of a luminous disc.

Choice of materials and color design
The luminaires are manufactured from EGS safety glass and aluminium. Standard diameter: Ø 400 mm. Available finishes: white; pendant also available in sand gold and rose gold. Custom colours can be produced on request to match interior concepts.

Versatile lighting solution
With a brilliant direct light component and a room‑opening indirect component, DIZCO generates atmospheres that support comfort and concentration, offering optimum visual comfort and high colour rendering. Suitable for high‑quality residential and commercial applications.

Lighting effect
The dot grid produces accentuated indirect light that creates the perception of a luminous disc within the transparent glass body. In ceiling and pendant versions, the indirect ambient light is supplemented by a brilliant downlight with a 60° beam angle, producing clear contours and enhancing colours and materials.

• Wall light: 100% indirect
• Pendant light: 50% direct, 50% indirect (separately controllable)
• Ceiling light: 70% direct, 30% indirect

Product variants
Available variants include:

• Ceiling luminaires (Ø 400 mm)
• Pendant luminaires (Ø 400 mm)
• Wall luminaires (Ø 400 mm)

Configure & options
Various control and configuration options are available (e.g. wireless control / Casambi integration as an option).

Technical specifications

• Model family: DIZCO
• Diameter: Ø 400 mm
• Materials: EGS safety glass (printed dot grid), aluminium
• Dot grid: approx. 60,000 printed dots (size increases from centre to edge)
• Lighting distribution: wall 100% indirect; pendant 50% direct / 50% indirect (separately controllable); ceiling 70% direct / 30% indirect
• Downlight beam angle (direct component): 60°
• High colour rendering (CRI 90 indicated)
• Protection / installation hint: IP20 indicated (see technical datasheets for details)
• UGR and visual comfort: UGR values indicated in technical literature (UGR 16–22 iconography)
• Tunable white range reference: TW 2200–5000
• Control options: Casambi (wireless) option possible
• Available finishes: white; pendant also in sand gold and rose gold; other colours on request
• Applications: suitable for high‑quality residential and commercial interiors
